VersaMax Series Analog Input Transmitter Module
The IC200ETM001 serves as an expansion transmitter module within the GE VersaMax platform. This module converts analog field signals into digital values for the control system. It accepts inputs from various sensors and transmitters. The unit then transmits processed data to the main controller.
Key Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | GE |
| Model | IC200ETM001 |
| Category | Expansion Transmitter Module |
| System Compatibility | VersaMax Series |
| Input Channels | Offers 4 differential analog inputs |
| Input Type | Accepts 4-20 mA or 0-10 Vdc signals |
| Resolution | Delivers 15-bit plus sign |
| Accuracy | Maintains ±0.1% of full scale |
| Conversion Rate | Processes 30 ms per channel |
| Power Supply | Draws +5 Vdc at 300 mA |
| Loop Power | Provides 24 Vdc at 20 mA per channel |
| Isolation | Offers 1500 Vac isolation |
| Diagnostics | Includes open-circuit detection |
| Operating Temperature | Functions from 0°C to +60°C |
| Storage Temperature | Withstands -40°C to +85°C |
| Dimensions | Measures 110.0 mm x 70.0 mm x 30.0 mm |
| Weight | Weighs approximately 0.3 kg |
| Mounting | Plugs into VersaMax terminal bases |
| Compliance | Meets CE, UL, and CSA standards |
Signal Conversion and Transmission
This transmitter module converts 4-20 mA current loops into digital data for processing. It also accepts 0-10 Vdc voltage signals from various sensors. The module performs high-resolution conversion with excellent accuracy. Moreover, it provides loop power to each connected field device. The unit communicates with the main controller over the expansion bus.
Installation and Configuration
First, mount the IC200ETM001 onto the VersaMax terminal base. Ensure the module locks securely into place. Next, connect the field instrument wiring to the designated terminal points. After that, apply power and observe the module status indicators. You can then configure the input range using the programming software.
Maintenance and Operational Reliability
This module includes diagnostic functions to detect open-circuit conditions. Therefore, you can quickly identify faulty field wiring. We recommend you verify the input readings against known values periodically. You should also inspect the terminal connections for tightness during routine checks.
Details
| Weight | 0.3 kg |
|---|---|
| Dimensions | 110 × 70 × 30 mm |
