This compact CPU module serves as the central controller for GE VersaMax PLC systems. It handles discrete logic operations and process control tasks in small to medium automation applications. The module integrates seamlessly with the full VersaMax I/O family for versatile system expansion.

CPU Performance and Memory Resources

The GE IC200CPU002 features a powerful 32-bit microprocessor that executes user logic swiftly and efficiently. It provides 10 KB of user program memory for ladder logic and Boolean instructions. The module also includes 10 KB of register memory for variable storage and data handling. An optional 10 KB floating point memory enables mathematical operations with decimal numbers. A memory retention feature uses supercapacitors to preserve data during brief power outages. A replaceable lithium battery maintains memory integrity during extended power losses.

Technical Specifications

System Architecture and I/O Expansion

This module supports up to 64 local I/O points, making it suitable for compact machine control. It can host up to 8 I/O modules directly attached to the CPU for local expansion. Remote I/O capability extends the system through a bus controller for larger distributed applications. Plugin terminal connectors simplify wiring and facilitate fast module replacement. The CPU uses pluggable memory cartridges for quick program transfers and backups.

Communication Interface and Application Use

The built-in RS-485 port supports SNP and RTU protocols for connectivity to HMI panels and other serial devices. This port enables data exchange with operator interfaces, drives, and other controllers. The module suits machine control, material handling, packaging, and other discrete manufacturing tasks. It also works well in building automation, conveyor systems, and simple process control applications. Its compact footprint makes it ideal for space-constrained control cabinets and panels.
