This analog input module converts field sensor signals into digital values for the controller. The GE HE693ADC409 provides four differential input channels with 16‑bit resolution. Each channel accepts voltage signals from -10 V to +10 V or current signals from 4‑20 mA. The module includes a programmable input filter for noise reduction on each channel. It samples all four inputs simultaneously with a 10 kHz update rate per channel.
Mechanical Dimensions and Construction Quality
The module measures 125 mm in height, 90 mm in depth, and 25 mm in width. This compact size conserves valuable space inside the control cabinet. Weighing only 0.28 kg, the HE693ADC409 simplifies handling during installation and maintenance. A rugged thermoplastic housing shields internal electronics from dust and physical damage. This housing meets IP20 requirements for safe indoor panel mounting.
Technical Specifications at a Glance
| Specification | Detail |
|---|---|
| Input Channels | 4 (differential) |
| Resolution | 16‑bit (1 part in 65,536) |
| Voltage Input Range | -10 V to +10 V |
| Current Input Range | 4‑20 mA (with external 250 Ω resistor) |
| Sampling Rate | 10 kHz per channel |
| Input Filter | Programmable (software configurable) |
| Accuracy | ±0.05% of full scale (25 °C) |
| Temperature Drift | ±50 ppm / °C |
| Dimensions (H × W × D) | 125 mm × 25 mm × 90 mm |
| Weight | 0.28 kg |
| Terminal Block | 16‑position screw clamp |
| Wire Gauge Range | 0.2 – 2.5 mm² |
| Backplane Current | 200 mA at 5 VDC |
| External Supply | 24 VDC ±10% |
| Power Dissipation | 3.0 W |
| Isolation Voltage | 500 VDC (channel‑to‑bus) |
| Energy Buffer | 47 µF capacitor (5 ms hold‑up) |
| Temperature Range | 0 °C to +60 °C |
| Humidity Range | 5% – 95% RH (non‑condensing) |
| Standards | UL 508, CSA, CE |
| Protection Rating | IP20 |
| Diagnostics | LED indicators (PWR, ACTIVE, FAULT) |
Interface and Connectivity Features
A 16‑position screw clamp terminal block provides secure and reliable field wiring connections. This terminal block accepts solid or stranded wires from 0.2 to 2.5 mm². Each input channel includes dedicated shield terminals for cable screening. The module also features a built‑in calibration reference for field verification. Front‑panel LEDs display power status, channel activity, and fault conditions clearly.
Power Architecture and Energy Storage
The GE HE693ADC409 draws 200 mA from the 5 VDC backplane for internal logic. It also needs a 24 VDC ±10% external supply for the analog circuitry. An onboard 47 µF capacitor provides short‑term energy storage for signal stability. This capacitor maintains conversion accuracy during power dips lasting up to 5 milliseconds. Total power dissipation remains at a low 3.0 W under full operation.
Internal Component Architecture
A 16‑bit successive‑approximation ADC handles the analog‑to‑digital conversion for each channel. The module includes a precision voltage reference with 10 ppm/°C temperature stability. Four independent instrumentation amplifiers condition the input signals before conversion. The PCB contains 85 surface‑mount resistors, 52 ceramic capacitors, and 4 operational amplifiers. A programmable filter allows software selection of cut‑off frequencies from 10 Hz to 500 Hz.
Environmental Performance and Certifications
This analog input module operates reliably from 0 °C to +60 °C in factory environments. It also performs consistently in humidity conditions from 5% to 95% without condensation. The HE693ADC409 complies with UL 508, CSA, and CE certification standards. These approvals guarantee safe integration into global industrial automation systems.
Details
| Weight | 0.28 kg |
|---|---|
| Dimensions | 125 × 25 × 90 mm |
