The complete model DS200TCSAG1A DS200TCSAG1ABB manages fuel skid signals for Mark V turbine systems. This board controls critical fuel delivery functions with high precision. It supports LM6000 and similar gas turbine applications reliably.

Technical Specifications

Signal Processing and Control Features

DS200TCSAG1A DS200TCSAG1ABB interfaces directly with fuel skid components. Its four relays switch fuel valve positions accurately. Six capacitors store energy for stable circuit operation. The board resides in R1 Core location 5. This placement ensures optimal signal routing for fuel controls.

Three connectors handle diverse field wiring tasks. processes flow meter inputs continuously. It also monitors fuel pressure transducers without delay. The board sends valve position feedback to the main processor. This feedback loop maintains safe combustion conditions.

Operational Integration

This interface board works seamlessly with the main turbine controller. It reduces external wiring through organized signal termination. DS200TCSAG1A DS200TCSAG1ABB prioritizes critical fuel path signals first. Only essential functions receive active connector assignments typically. The remaining ports serve diagnostic or expansion needs later.

Physical and Installation Notes

Manufacturers reference manual GEH-6195 for all installation steps. Each DS200TCSAG1A DS200TCSAG1ABB unit undergoes full functional testing. We clean every board before final shipment. The secondary code DS200TCSAG1ABB appears on the factory label. This board weighs approximately 1.2 pounds for easy handling.
