Product Overview
The GE DS200TCQBG1BCB functions as a critical analog I/O board within the Mark V turbine control system. This board interfaces directly with field sensors and actuators, managing critical process signals for turbine operation. Furthermore, the DS200TCQBG1BCB ensures precise data conversion between analog field devices and the digital control core.
Technical Specifications
The DS200TCQBG1BCB features multiple analog input and output channels for comprehensive signal handling. This board uses a 60-pin connector to interface with the Mark V backplane, ensuring reliable signal transmission. Additionally, the board includes integrated transient suppression circuitry that protects against voltage spikes and electrical noise.
| Parameter | Specification |
|---|---|
| Manufacturer | GE (General Electric) |
| Product Type | Analog I/O Board |
| System Platform | Mark V Turbine Control |
| Connector Type | 60-pin (backplane interface) |
| Analog Inputs | Multiple channels (configurable) |
| Analog Outputs | Multiple channels (configurable) |
| Voltage Range | 0-5 VDC (typical I/O levels) |
| Signal Conditioning | On-board filtering and amplification |
| Protection | Transient suppression circuitry |
| Dimensions | 25 mm x 130 mm x 110 mm |
| Net Weight | Approx. 1.2 kg |
| Origin | USA |
Key Design Features
The DS200TCQBG1BCB incorporates on-board signal conditioning for accurate data acquisition. Its transient suppression circuitry effectively safeguards the module from common industrial power disturbances. This robust design ensures reliable operation in the harsh electrical environments typical of power generation facilities.
Application and Integration
The DS200TCQBG1BCB integrates seamlessly into Mark V turbine control cabinets across gas and steam turbine installations. Maintenance teams rely on this board for accurate monitoring of temperature, pressure, and flow parameters. Consequently, it plays a vital role in ensuring turbine efficiency and safe operation.
Details
| Weight | 1.2 kg |
|---|---|
| Dimensions | 25 × 130 × 110 mm |
