The GE DS200TCDAH1B DS200TCDAH1BJE provides discrete input and output processing for Mark V turbine controls. You can install this board into the main turbine control cabinet. It interfaces with field devices and status indicators. This board suits gas and steam turbine monitoring and sequencing applications.

Technical Specifications and Hardware Layout

The GE DS200TCDAH1B DS200TCDAH1BJE measures 280 mm in height. Its width reaches 185 mm, and the depth equals 30 mm. The GE DS200TCDAH1B DS200TCDAH1BJE weighs approximately 0.45 kilograms. A single multilayer PCB holds all input and output circuits. The board contains no energy storage capacitors or batteries. Two 50-pin ribbon connectors provide system interface connections. Three terminal blocks handle field wiring for I/O signals. Six test points allow signal monitoring with a multimeter.

Digital I/O Specifications

The GE DS200TCDAH1B DS200TCDAH1BJE provides sixteen digital input channels. It accepts 24 V DC signals from field switches and sensors. This board also delivers eight digital output channels for actuator control. Each output switches 0.5 A at 24 V DC continuously. Consequently, this board manages turbine sequencing and interlock logic. Input channels include debounce filters for noise rejection. Output channels provide short-circuit protection for fault tolerance. Optical isolation separates the field side from the backplane logic.

Installation and Diagnostic Features

You must insert the GE DS200TCDAH1B DS200TCDAH1BJE firmly into a dedicated Mark V rack slot. Transitioning to wiring, use 0.5 mm² to 1.5 mm² stranded copper wire. Six front LEDs show power, input status, and output activity clearly. For troubleshooting, use the six test points with a multimeter. Always power off the system before removing or inserting the board. The operating temperature range spans from -20°C to +55°C reliably.
