This communication board manages data exchange between drive components and external networks. It supports multiple industrial communication protocols for system integration. The unit mounts inside the drive cabinet as a network interface card.
Technical specifications
| Parameter | Specification |
|---|---|
| Brand | GE Energy |
| Model 1 | DS200MBHAG1A |
| Model 2 | DS200MBHAG1AGD |
| Product Family | Mark V / Drive Control |
| Category | Communication Board |
| PCB Layer Count | 6 layers |
| Base Material | High-Tg FR-4 |
| Processor Type | 32-bit communication processor |
| Processor Speed | 80 MHz |
| Memory | 512 KB Flash, 256 KB RAM |
| Communication Ports | 1 x Ethernet (RJ-45), 2 x RS-232, 2 x RS-485 |
| Protocols Supported | MODBUS TCP, MODBUS RTU, PROFIBUS, Ethernet/IP |
| Data Rate (Ethernet) | 10/100 Mbit/s |
| Data Rate (Serial) | 300 to 115.2 kbit/s |
| Component Count | Approximately 130 components |
| Integrated Circuits | 18 ICs (processor, transceivers, memory) |
| Connector Types | 1 x RJ-45, 4 x D-sub (9-pin), 2 x headers |
| Power Supply | 24V DC external |
| Current Consumption | 260 mA typical |
| Status Indicators | 5 x LEDs (PWR, RUN, TX, RX, LINK) |
| Test Points | 8 gold-plated test points |
| Energy Storage | 8 x electrolytic capacitors (47 µF each) |
| Dimensions (L x W) | Approx. 24 cm x 16 cm |
| Thickness | Approx. 1.6 mm |
| Weight | Approx. 0.34 kg |
| Operating Temperature | 0°C to 55°C |
| Mounting | 4 x screw holes (M4) |
Detailed Technical Analysis
This communication board uses an 80 MHz processor for fast protocol handling. It supports Ethernet at 10/100 Mbit/s for high-speed networking. The board also provides two RS-232 and two RS-485 serial ports. It stores its firmware in 512 KB of flash memory permanently.
Now let us examine its protocol support. The board handles MODBUS TCP, MODBUS RTU, PROFIBUS, and Ethernet/IP. Approximately 130 components populate both sides of this 6-layer PCB. Eighteen integrated circuits include the communication processor and transceivers. Eight electrolytic capacitors filter the power supply for stable operation.
This communication board draws 260 milliamps from a 24V DC external supply. Five LEDs show power, run, transmit, receive, and link status. Eight gold-plated test points allow network signal verification. The GE DS200MBHAG1A DS200MBHAG1AGD supports baud rates from 300 to 115.2 kbit/s on serial ports.
Installation and Configuration Guidelines
You mount this board using four M4 screws with insulating standoffs. Connect the 24V DC power supply to the designated terminal block. Attach Ethernet and serial cables to the appropriate ports. The board automatically negotiates link speed on Ethernet ports.
Configure the communication parameters through the drive programming software. Set IP addresses, baud rates, and protocols for each port. The board stores configuration in non-volatile flash memory. Always power down the drive before inserting or removing this board.
Practical Applications
Engineers use this communication board for drive network integration and connectivity. It connects drives to PLCs, HMIs, and SCADA systems. This component also works in legacy drive upgrade projects. Its multiple ports suit complex industrial network configurations.
Summary of Features
To conclude, this communication board supports Ethernet and four serial ports at up to 115.2 kbit/s. It weighs 0.34 kilograms and draws 260 milliamps at 24V. Choose DS200MBHAG1A DS200MBHAG1AGD for reliable drive network communication.
