The DS200KLDCF1A DS200KLDCF1AAB provides firmware storage for GE Mark V turbine systems. This PROM set contains the operating software for key controller functions. You can rely on it for system initialization and program execution.
Key Technical Parameters
The table below lists all essential technical specifications for this software PROM set.
| Specification | Details |
|---|---|
| Part Numbers | DS200KLDCF1A DS200KLDCF1AAB |
| Product Type | Software PROM Set |
| Compatibility | GE Mark V turbine control series |
| Memory Type | EPROM (UV erasable) |
| Storage Capacity | 512 KB per PROM |
| Number of PROMs | 2 chips per set |
| Total Firmware Size | 1 MB |
| Access Time | 150 ns |
| Operating Voltage | 5V DC ±5% |
| Number of Components | 2 EPROMs, 1 label sheet |
| Dimensions (per chip) | 32 mm x 14 mm x 4 mm |
| Total Weight | Approx. 0.02 kg |
| Pin Configuration | 32-pin DIP (dual in-line) |
| Operating Temperature | -20°C to 65°C |
| Data Retention | 10 years minimum |
Physical Characteristics and Installation
This software PROM set weighs approximately 0.02 kg for lightweight handling. Each chip measures 32 mm x 14 mm x 4 mm for standard DIP sockets. First, power down the Mark V controller completely. Then, remove the existing PROMs from their sockets. Finally, insert the DS200KLDCF1A DS200KLDCF1AAB chips with proper orientation. The label sheet identifies the correct firmware version for your system.
Memory Specifications and Firmware Content
The DS200KLDCF1A DS200KLDCF1AAB includes two EPROM chips per complete set. Each PROM provides 512 KB of storage capacity. The total firmware size reaches 1 MB for comprehensive system software. An access time of 150 ns ensures fast program execution. The EPROM technology retains data for 10 years minimum without power. UV erasure allows firmware updates if necessary.
PROM Variants and Compatibility
The “AAB” suffix indicates a specific firmware revision for the key/LED/display board. Different suffix letters contain different software versions. Always verify your existing PROM revision before ordering a replacement. The DS200KLDCF1A DS200KLDCF1AAB set matches specific Mark V system configurations. These chips require 5V DC supply with ±5% tolerance. Each chip uses a standard 32-pin DIP package for easy replacement.
