Engineered for Mark V Speedtronic I/O Processing

This board processes input and output signals for the drive system. It provides reliable signal conditioning for the GE DS200IOMAF1B DS200IOMAF1BDE module. You will find this unit exclusively in the Mark V turbine control series. Unlike standard I/O boards, this version uses the “BDE” functional revision. It manages up to 32 discrete signal channels simultaneously.

Technical Specifications & Physical Dimensions

We designed this IC board for high-density signal handling. The table below presents all verified technical specifications.

Functional Architecture and Pin Layout

This IC board connects directly to the Mark V backplane. It uses 32 pins for discrete signal processing. You can configure each pin as an input or output. Moreover, the module includes four buffer integrated circuits. These components isolate signals from electrical interference. Consequently, the board delivers clean I/O data to the main processor.

Installation and Operational Guidelines

The GE DS200IOMAF1B DS200IOMAF1BDE operates at 24 MHz clock speed. It scans all 32 channels within 2 milliseconds. You must verify the pin mapping before installing this board. Always match the connector labels J1 through J4 correctly. This procedure prevents incorrect signal routing to the drive. Furthermore, the board supports both AC and DC input types. This feature provides flexibility for different field devices.

Physical Characteristics and Environmental Limits

This IC board has a compact, single-layer PCB construction. Its lightweight 0.22 kg structure allows for easy replacement. The layout follows GE’s standard Mark V coating specifications. Therefore, it fits seamlessly into existing I/O racks. The board includes LED indicators for each active channel. In addition, it maintains stable operation between -25°C and 60°C ambient temperature. You can store this unit safely up to 85°C.
