Why This Regenerative Board Returns Energy to the Line
This common DC bus regenerative board converts excess DC energy back to AC power. You get an efficient GE DS200GSIAG1A DS200GSIAG1ABA for multi-drive systems. It connects across the shared DC bus of several inverters. Therefore, your system reduces energy waste and lowers operating costs.
Technical Specifications and Physical Details
The GE DS200GSIAG1A DS200GSIAG1ABA contains six IGBTs in a three-phase bridge configuration. It synchronizes with the AC line for regenerative power flow. This board mounts onto the main drive chassis. Its dimensions measure approximately 320 mm in width and 230 mm in height. The unit weighs around 1.10 kg for secure installation. This regenerative board stores minimal energy internally. Instead, it transfers power directly from the DC bus to the AC line. Consequently, you need no large braking resistors for most applications.
Below is the detailed breakdown of the hardware specifications.
| Parameter | Specification |
|---|---|
| Product Model | DS200GSIAG1A DS200GSIAG1ABA |
| Product Type | Common DC Bus Regenerative Board |
| Brand | GE (General Electric) |
| Power Devices | 6 IGBTs (three-phase bridge) |
| Function | DC to AC power regeneration |
| Connection | Shared DC bus + AC line |
| Mounting Type | Chassis mount |
| Dimensions (W x H) | Approx. 320 x 230 mm |
| Approx. Weight | 1.10 kg |
| Energy Storage | Minimal (direct transfer) |
| Component Count | Single populated PCB |
Installation and System Integration
This board connects between the common DC bus and the AC supply. You must install AC line reactors for harmonic filtering. The GE DS200GSIAG1A DS200GSIAG1ABA requires proper sequencing with connected drives. Therefore, enable regeneration only after the DC bus reaches nominal voltage. Always verify phase rotation before applying power. Incorrect phasing will cause a direct short across the AC line.
