Technical Overview
The GE DS200FSAAG2ABA DS2020FECNRX010A set forms a comprehensive field supply and excitation solution for the Mark V turbine control system. This GE DS200FSAAG2ABA DS2020FECNRX010A combination amplifies low-voltage control signals into robust drive signals for field actuators and instruments. This GE DS200FSAAG2ABA DS2020FECNRX010A duo also provides regulated 24V DC power to various field devices, ensuring stable and reliable operation. The GE DS200FSAAG2ABA DS2020FECNRX010A set shares common applications within the Mark V series, offering high-current excitation with a 24A NRX capability and a 10A shunt for enhanced protection. Moreover, the GE DS200FSAAG2ABA DS2020FECNRX010A unit integrates seamlessly into the Mark V rack system, occupying designated slots with standard backplane connectors.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | GE (General Electric) |
| Model Numbers | DS200FSAAG2ABA DS2020FECNRX010A |
| Product Type | Field Supply Amplifier Board / Field Exciter Module |
| System Compatibility | GE Speedtronic Mark V & Mark VI |
| Input Voltage | 115-230 VAC (expandable 90-260 VAC) |
| Output Voltage | 24V DC |
| Output Current | Up to 10A (continuous) |
| Power Requirement | +5V DC, 6A (for board logic) |
| Relay Channels | 12 |
| Excitation Current | 24A NRX capability (DS2020FECNRX010A) |
| Shunt Rating | 10A (DS2020FECNRX010A) |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -55°C to +85°C |
| Dimensions | 28.9 x 19.2 x 12.1 cm (approx.) |
| Weight | 2.27 kg (5 lbs) |
| Fuses | 2 x 30A, 60V fast-acting |
| Connectors | 1x 10-pin, 4x 2-pin |
| Jumpers | 5 (JP1-JP5) for configuration |
| Test Points | Multiple for diagnostics |
| Country of Origin | USA |
Key Features
High-Capacity Field Power Supply – The GE set provides up to 10A at 24V DC, ensuring sufficient power for multiple field devices.
Versatile Connectivity – This GE includes 5 jumpers, one 10-pin connector, and four 2-pin connectors, enabling flexible system integration.
Comprehensive Diagnostics – Multiple test points on the GE modules simplify troubleshooting and reduce maintenance time.
Robust Protection – Overcurrent, overvoltage, and overtemperature safeguards ensure reliable operation in harsh environments.
Wide Temperature Tolerance – The GE modules operate reliably from -40°C to +70°C, making them suitable for demanding applications.
Applications
The GE DS200FSAAG2ABA DS2020FECNRX010A set is ideal for power generation, oil and gas, and industrial process control. These modules are specifically designed for turbine control systems, generator excitation controls, and heavy-duty industrial drives.
Details
| Weight | 0.1 kg |
|---|---|
| Dimensions | 25 × 108 × 127 mm |
