Why This Control Module Executes Your Drive Logic
This control PLC module handles all sequencing and regulation tasks. You get a powerful GE DS200FCGDH1B DS200FCGDH1BCA for industrial drive systems. It processes feedback signals and generates firing pulses for thyristors. Therefore, your drive maintains stable motor operation under varying loads.
Technical Specifications and Physical Details
The GE DS200FCGDH1B DS200FCGDH1BCA features a dedicated microprocessor with onboard memory. It includes multiple analog and digital I/O channels for field connections. This module plugs directly into a VME backplane slot. Its dimensions measure approximately 233 mm in height and 20 mm in width. The unit weighs around 0.32 kg for straightforward installation. This control module stores its firmware in flash memory. Consequently, you can update the operating system without replacing the hardware.
Below is the detailed breakdown of the hardware specifications.
| Parameter | Specification |
|---|---|
| Product Model | DS200FCGDH1B DS200FCGDH1BCA |
| Product Type | Control PLC Module |
| Brand | GE (General Electric) |
| Processor | Dedicated microprocessor |
| Memory Type | Flash + RAM |
| I/O Channels | Analog and digital |
| Interface | VME backplane |
| Slot Requirement | 1 VME slot |
| Dimensions (H x W) | Approx. 233 x 20 mm |
| Approx. Weight | 0.32 kg |
| Energy Storage | Flash memory (firmware) |
| Component Count | Single populated PCB |
Installation and Programming Notes
This module inserts into any compatible VME backplane slot. You must align the card with the upper and lower guides. The GE DS200FCGDH1B DS200FCGDH1BCA requires configuration software for parameter adjustment. Therefore, connect a programming terminal before commissioning. Always handle this board by its metal ejector handles only. Static discharge from your fingers will damage sensitive microprocessor components.
Details
| Weight | 0.1 kg |
|---|---|
| Dimensions | 25 × 108 × 127 mm |
