The DS200CVMAG3A DS200CVMAG3AEB manages generator voltage and frequency regulation tasks. This board executes turbine control algorithms with 16-bit processing precision. It integrates seamlessly into Mark V series control racks.

Key Technical Specifications

Physical Dimensions and Component Layout

This board measures 23.0 cm in length and 14.5 cm in width. Its total height reaches 3.8 cm including all components. DS200CVMAG3A DS200CVMAG3AEB weighs only 0.95 kg for easy handling. You will find 156 discrete components on an eight-layer PCB.

Furthermore, the board includes a 2200 µF backup capacitor bank. This bank stores enough energy for a 30-second data retention during power loss. It also smooths voltage fluctuations for sensitive analog circuits.

Connector Interfaces and Signal Routing

The front panel features two 37-pin D-sub connectors for field I/O wiring. A separate 50-pin header connects to the VME backplane for data exchange. Two LED indicators show board status and heartbeat activity. A JTAG port sits near the top edge for firmware updates.

Thermal Management and Processing Power

The main processor runs at 40 MHz with a passive heat spreader. This design removes heat without requiring active cooling fans. Consequently, the board operates reliably in vibration-prone turbine environments. The eight-layer PCB reduces electromagnetic interference between analog and digital sections.

Typical Application Scenarios

You can deploy DS200CVMAG3A DS200CVMAG3AEB in gas turbine generator control panels. It also works well for steam turbine synchronization and protection systems. This board manages excitation control and load sharing tasks. Its 1MB flash memory stores critical turbine configuration parameters.
