This GE Industrial contactor provides reliable switching for motors and resistive loads in industrial settings. It handles continuous currents up to 60 A across three main poles. Engineers can deploy this unit for pump, compressor, and conveyor applications with confidence. Its rugged construction withstands frequent operations in demanding manufacturing environments. The contactor simplifies panel integration through straightforward mounting and wiring provisions.

Physical Dimensions and Mounting Configuration

The contactor measures 4.3 inches in width and 5.1 inches in height. Its robust housing weighs approximately 2.8 pounds for stable panel installation. Four mounting holes accommodate M4 screws for secure attachment to backplates. The unit features a compact footprint that conserves valuable enclosure space. This design allows side-by-side mounting with minimal clearance requirements.

Contact Configuration and Load Ratings

The device incorporates 3 normally-open main contacts for three-phase power switching. Each pole carries a continuous current rating of 60 A at 600 VAC. The contactor also includes 1 normally-open and 1 normally-closed auxiliary contact. These auxiliary contacts facilitate interlocking and status feedback circuits. The main contacts utilize silver-alloy materials for excellent conductivity and arc resistance.

Coil Specifications and Control Voltage

The AC coil operates on a standard 120 VAC control supply at 60 Hz. The coil draws 8.5 VA during pickup and 4.5 VA during sealing. This power consumption ensures compatibility with standard PLC output modules. An encapsulated coil design protects against moisture and contaminant ingress. The coil withstands continuous energization without overheating or insulation breakdown.

Switching Performance and Electrical Durability

The contactor achieves a mechanical life of 10 million operations under normal conditions. Its electrical life reaches 500,000 operations at rated load for extended service. The unit incorporates arc chutes for effective extinguishing during contact opening. These arc chambers minimize contact erosion and extend operational lifespan. The contactor also features a magnetic blow-out system for rapid arc extinction.

Thermal Management and Energy Storage

The device dissipates approximately 8.5 watts of heat during normal sealed operation. Its open-frame construction promotes natural convection cooling without auxiliary fans. The contactor includes no internal energy storage components for passive design. This simplicity reduces potential failure points and enhances overall reliability. The unit maintains full current capacity up to 40 degrees Celsius ambient temperature.

Environmental Ratings and Compliance Standards

The contactor operates reliably from -25 to 55 degrees Celsius for versatile deployment. It meets NEMA and IEC standards for industrial control equipment globally. The unit withstands vibration up to 10 g for rugged transportation applications. Its silver-plated terminals accept wire sizes from 14 to 4 AWG conveniently. This terminal flexibility simplifies field wiring and reduces installation labor.
