The GE A16B-1200-0310/03B graphic interface punch board manages display and operator interface signals within GE Fanuc CNC control platforms. Engineers install this board to drive graphic displays and process panel input commands. Consequently, it serves machine tools, robotics cells, and factory automation operations.

Technical Specifications and Hardware Details

This board occupies a dedicated slot inside a compatible GE Fanuc control rack. It measures roughly 250 mm long, 180 mm wide, and 20 mm thick, while it weighs about 0.5 kg. Moreover, the board carries display output connectors and panel input terminals.

Functional Capabilities and System Integration

The board drives graphic display signals while it reads operator panel input commands. Meanwhile, the backplane connector links it to the main CPU and control bus. Dedicated output connectors support CRT and LCD displays, therefore operators view machine status clearly.

Additionally, the design processes keypad and switch signals for menu navigation. As a result, technicians interact with the CNC system efficiently during setup. Clear connector labeling helps maintenance crews trace signals quickly. Natural convection cools the board inside standard control cabinets.

Installation and Maintenance Guidelines

Technicians should power down the rack before they insert the A16B-1200-0310/03B board. Afterward, verifying display and panel connections confirms reliable signal transfer. Periodic inspection of ribbon cables prevents loose contacts and screen faults. Finally, consult GE documentation for display compatibility and connector pinouts.
