Overview
The A06B-6078-K001 16B belongs to the GE Fanuc family of cooling fans for servo drive units. Engineers deploy this fan to dissipate heat from drive modules inside CNC control cabinets. Consequently, it protects power stages from thermal overload during continuous operation.
Key Technical Specifications
The A06B-6078-K001 16B provides forced-air cooling for GE Fanuc drive units. Moreover, it mounts directly onto the drive housing for targeted airflow. The table below lists the core parameters.
| Parameter | Specification |
|---|---|
| Product Type | Drive unit cooling fan |
| Series | GE Fanuc servo drive accessories |
| Fan Type | Axial, forced-air |
| Nominal Voltage | 24 VDC or 200 VAC |
| Power Consumption | Approximately 12 W |
| Airflow | 100 m³/h nominal |
| Speed | 2,800 RPM typical |
| Noise Level | 45 dB(A) typical |
| Bearing Type | Ball bearing |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | –20 °C to +70 °C |
| Humidity | 5–95%, non-condensing |
| Dimensions | 120 mm × 120 mm × 38 mm |
| Weight | Approximately 0.4 kg (0.88 lb) |
| Mounting | Direct drive housing attachment |
| Compliance | CE, UL |
Installation and Interface Details
The fan mounts directly onto the drive unit housing with standard screws. Power then connects through a two-pin plug, which simplifies replacement. Furthermore, the compact 120 mm frame fits existing mounting holes without modification. As a result, technicians swap failed fans quickly during routine maintenance.
Cooling Performance and Airflow
The axial design moves 100 m³/h of air across the drive heat sink. Meanwhile, the 2,800 RPM speed maintains consistent cooling under load. Additionally, the ball bearing construction extends service life in continuous duty. Therefore, the fan keeps power stages within safe temperature limits.
Environmental and Mechanical Ratings
The fan operates from 0 °C to +60 °C in typical cabinet conditions. Moreover, the sealed motor tolerates 5–95% relative humidity without condensation. The compact footprint of 120 mm × 38 mm fits crowded enclosures. Consequently, the fan suits machining centers, lathes, and robotic cells.
Why Engineers Choose This Fan
This fan offers several practical advantages. First, it mounts directly onto GE Fanuc drive units. Second, the two-pin plug simplifies field replacement. Third, its ball bearings extend service life under continuous duty. Therefore, maintenance teams reduce downtime and replacement costs.
Details
| Weight | 0.15 kg |
|---|---|
| Dimensions | 110 × 72 × 38 mm |
