Dual-Axis Servo Amplifier for Precision Motion Control
The GE A06B-6066-H244 is a high-performance AC servo amplifier module designed for dual-axis control in demanding automation applications. This unit belongs to the FANUC Servo Amplifiers family and specifically falls under the SVUC2 series, a classification that denotes its advanced digital control capabilities . Its primary function is to deliver precise position, speed, and torque control for two servo motors simultaneously, making it an essential component in sophisticated CNC machining centers, robotics, and automated manufacturing lines .
Electrical Performance and Power Specifications
The GE A06B-6066-H244 handles a wide range of industrial power requirements. It accepts a 3-phase input voltage from 200 to 240 VAC, adaptable to 50 or 60 Hz power grids, with robust tolerances of +10% and -15% . Consequently, this flexibility ensures compatibility with diverse global electrical standards. The module’s dual-axis design can deliver a peak current of 40A per axis, with a maximum power output ranging from 0.5 to 15 kW depending on the connected motor ratings .
Physical Dimensions and Installation
Weighing approximately 5.7 kg (12.5 lbs) and measuring 8.9 cm x 29.2 cm x 12.7 cm (3.5 in x 11.5 in x 5.0 in), the A06B-6066-H244 features a compact, rack-mountable enclosure . It requires vertical or wall mounting for proper operation. The unit employs forced air cooling to maintain optimal operating temperatures between 0°C and 45°C . Therefore, ensuring adequate ventilation is crucial for reliability.
Protection and System Integration
This servo amplifier includes comprehensive protection mechanisms against overloads, overcurrent, overvoltage, and overheating . It integrates seamlessly with FANUC control systems using standard digital and analog inputs, providing robust performance for critical manufacturing tasks .
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | A06B-6066-H244 |
| Type | AC Servo Amplifier / Servo Drive |
| Manufacturer | GE Fanuc |
| Axis Control | Dual-Axis |
| Control Type | Position, Speed, Torque |
| Input Voltage | 200/220/230 VAC (±10% / -15%) |
| Frequency | 50/60 Hz |
| Peak Output Current | 40A per axis |
| Weight | Approx. 5.7 kg (12.5 lbs) |
| Dimensions (H x W x D) | 29.2 x 8.9 x 12.7 cm (11.5 x 3.5 x 5.0 in) |
| Cooling Method | Forced Air Cooling |
| Protection Features | Overload, Overcurrent, Overvoltage, Thermal |
Details
| Weight | 5.7 kg |
|---|---|
| Dimensions | 292 × 89 × 127 mm |
