The 4116J89-G02 circuit board from GE supports signal processing and control functions inside industrial drive and automation cabinets. Maintenance teams order this board when a legacy system needs a dependable replacement or spare. Consequently, it keeps production equipment running without a full control upgrade.
Key Technical Specifications
The table below outlines the main physical and electrical parameters of the 4116J89-G02 board.
| Parameter | Specification |
|---|---|
| Product Type | Circuit Board |
| Compatibility | GE industrial drive and control systems |
| Dimensions | Approximately 250 mm x 180 mm x 20 mm |
| Weight | Approximately 0.45 kg (1.0 lbs) |
| Mounting | Cabinet backplane or card cage slot |
| Interface | Backplane bus and ribbon cable connectors |
| Connectors | Multiple edge connectors and pin headers |
| Component Count | Numerous integrated circuits, resistors, and capacitors |
| Energy Storage | On-board capacitors for signal and voltage stabilization |
| Board Function | Signal processing and control logic support |
| Operating Temperature | 0 degrees C to 60 degrees C |
| Storage Temperature | -40 degrees C to 85 degrees C |
| Humidity | 5% to 95% non-condensing |
Functional Overview
This board processes incoming signals and routes them to the appropriate control circuits. Therefore, it supports regulation, monitoring, and protection tasks within the drive cabinet. The 4116J89-G02 also carries onboard energy storage that smooths voltage ripple on critical rails. Meanwhile, its connector layout matches the original mounting arrangement for straightforward replacement.
Installation and Handling Notes
Always record existing settings before removing the 4116J89-G02 from its cage. In addition, observe anti-static precautions when handling the board. Seat all edge connectors fully and secure every retaining screw. Finally, verify supply voltages after installation.
Details
| Weight | 0.15 kg |
|---|---|
| Dimensions | 110 × 72 × 38 mm |
