This power management relay protects motors and monitors electrical parameters continuously. It provides advanced protection functions for industrial motor control applications. Therefore, this component suits pumps, fans, compressors, and conveyors.
Physical Dimensions and Weight Specifications
The GE 269PLUS-100P-120 features a rugged panel-mount housing for industrial use. Its width measures 144 mm for standard cutout dimensions. The total depth reaches 145 mm including the rear terminals. Consequently, technicians can install this unit in distribution panels or motor control centers.
| Parameter | Specification |
|---|---|
| Product Model | GE 269PLUS-100P-120 |
| Width | 144 mm |
| Height | 144 mm |
| Depth | 145 mm |
| Weight | 1.2 kg |
Interface Types and Connection Layout
The GE 269PLUS-100P-120 provides screw-clamp terminals for CT and PT wiring. A separate RS-485 port supports Modbus communication with SCADA systems. The front panel carries a backlit LCD display for local monitoring. Hence, operators can view real-time power readings directly on the unit.
Component Count and Measurement Capabilities
This relay contains one main board with a 32-bit DSP processor. The board holds 128 KB of memory for event logging. You will also find three current transformer inputs and four voltage inputs. An onboard power supply accepts 120V AC control power directly.
| Technical Feature | Description |
|---|---|
| CT Inputs | 3 phase, 1A or 5A selectable |
| Voltage Inputs | 4 (3-phase + neutral), 120V AC |
| Protection Functions | Overload, ground fault, short circuit |
| Measurement Accuracy | ±1% for current and voltage |
| Communication | RS-485 Modbus RTU |
Energy Storage and Power Requirements
The GE 269PLUS-100P-120 draws 15 VA from the 120V AC supply. A supercapacitor maintains event logs for 7 days without control power. This storage preserves fault data during power interruptions. Therefore, technicians can analyze the last event after a system outage.
Protection Settings and Operational Features
Users can configure up to 40 protection parameters via the front keypad. The relay stores 16 time-stamped events for diagnostic purposes. A programmable output relay trips the motor circuit breaker. This feature provides comprehensive motor protection in one device.
Details
| Weight | 0.1 kg |
|---|---|
| Dimensions | 25 × 108 × 127 mm |
