The Fuji NV1X3204 digital input card captures discrete field signals for industrial automation systems. Engineers choose this unit for dependable signal acquisition across manufacturing and process environments. Moreover, its compact housing supports straightforward integration into existing control panels.
Interface and Connectivity
The card connects through a dedicated backplane connector for fast data exchange. Additionally, it provides thirty-two input points for field devices. These terminals accept 24 VDC signals, therefore covering common industrial wiring standards. Field wiring uses screw-terminal blocks that reduce installation time considerably.
Physical Dimensions and Weight
The unit measures 28.6 mm in width, 100 mm in height, and 90 mm in depth. Furthermore, it weighs approximately 150 grams, which reduces panel load. Consequently, technicians mount it easily on standard DIN rails.
Component Count and Energy Storage
The NV1X3204 integrates thirty-two optocoupler isolation circuits for channel protection. It also contains one filtering capacitor rated at 220 µF for stable readings. Therefore, this energy storage element suppresses ripple during rapid signal changes. The board carries roughly 200 discrete components for dependable operation.
Technical Specifications Table
| Parameter | Specification |
|---|---|
| Model | NV1X3204 |
| Category | Digital Input Card |
| Input Points | 32 |
| Rated Voltage | 24 VDC |
| Dimensions (W×H×D) | 28.6 × 100 × 90 mm |
| Weight | ~150 g |
| Connector Type | Backplane / Screw Terminal |
| Energy Storage | 220 µF Capacitor |
| Operating Temperature | 0°C to 55°C |
Why This Card Suits Industrial Applications
System integrators value the NV1X3204 for its stable signal acquisition and simple wiring. Meanwhile, the optocoupler isolation protects sensitive circuits from voltage spikes. As a result, system reliability improves while maintenance costs decrease.
