This input module captures digital signals from field sensors and switches for remote control systems. It integrates seamlessly into the Fuji Electric Micro-SX and SPH series automation platforms. The unit monitors up to eight independent input channels from a single remote location. Users can connect proximity sensors, limit switches, and pushbuttons with reliable performance.

Input Channel Configuration and Electrical Specifications

This module features eight digital input channels for versatile field connectivity. Each channel accepts 24 V DC signals from 0 V to 30 V for broad compatibility. The input current per channel measures approximately 3.5 mA at nominal voltage. Each input includes built-in filtering for reliable noise rejection. The channels are electrically isolated from the communication bus.

Signal Processing and Response Performance

The NR2JAX-08VMRDT processes each input signal with high-speed response and reliability. Input response times remain under 1 ms for fast event detection. Each channel includes built-in filtering for reliable noise rejection. The module also provides input status LEDs for real-time visualization. This performance suits packaging machinery and fast-moving assembly lines. Consequently, operators receive accurate and timely sensor feedback.

Network Communication and T-Link Integration

This module communicates with the master controller via the T-Link remote bus protocol. The dedicated protocol ensures deterministic data exchange for real-time control. The module supports a maximum transmission distance of 200 m between stations. Users can connect up to 31 remote modules on a single T-Link network. This architecture enables distributed input monitoring across large production facilities. Consequently, engineers can design scalable systems with minimal wiring complexity.

Diagnostic Indicators and Status Monitoring

Front-panel LEDs provide clear visual feedback for operators and technicians. A green “Power” LED confirms the presence of supply voltage. A “Run” LED indicates normal communication with the master controller. A red “Error” LED signals network faults or module malfunctions. Individual green LEDs show the status of each input channel. These indicators simplify troubleshooting without requiring programming software.

Energy Consumption and Environmental Tolerance

The module draws 20 mA at 24 V DC from the remote bus power supply. This low consumption minimizes the load on the network power source. Power dissipation remains below 1 W under normal operating conditions. Consequently, the operating range spans 0 °C to 55 °C for standard factory environments. Humidity tolerance reaches 10% to 90% without condensation issues.

Mounting Flexibility and Mechanical Durability

The module features a compact housing suitable for DIN rail or direct mounting. Its small footprint fits into tight control cabinets and junction boxes. The unit carries an IP20 rating for protection against solid objects. Furthermore, the module resists vibration up to 0.75 g for industrial durability. This robust design suits automotive assembly, material handling, and food processing applications.
