Product Overview
The Fuji NR2JAX-08IMRDT enables serial communication between the controller and external devices. This module interfaces with operator panels, programming tools, and other automation equipment. It provides reliable data exchange for Fuji Electric systems. The unit fits into compatible Fuji NR series rack-mounted chassis.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | NR2JAX-08IMRDT |
| Product Type | Communication Module |
| Communication Interface | RS-232 serial port |
| Port Type | 9-pin D-sub connector (male) |
| Data Format | Asynchronous, start-stop |
| Baud Rate | 300 to 19,200 bps selectable |
| Data Bits | 7 or 8 bits configurable |
| Parity | None, odd, even selectable |
| Stop Bits | 1 or 2 bits configurable |
| Transmission Distance | Up to 15 meters |
| Signal Levels | RS-232 compatible |
| Power Supply | 5 VDC from backplane |
| Power Dissipation | 2.8 W typical |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | –20°C to 70°C |
| Humidity Range | 10% to 90% non-condensing |
Physical Dimensions and Construction
This communication module measures 250 mm in width, 30 mm in height, and 160 mm in depth. The unit weighs approximately 0.35 kg. It plugs directly into the NR series backplane connector. The front panel includes LED indicators for power, transmit, and receive activity. These LEDs show communication status at a glance.
Serial Interface and Connectivity
The NR2JAX-08IMRDT features a 9-pin D-sub connector on the front panel. This connector provides RS-232 signal levels for standard serial communication. It supports transmit, receive, and hardware handshaking signals. The module accommodates both DTE and DCE device connections. The transmission distance covers up to 15 meters for flexible system layouts.
Communication Protocol and Data Handling
This module supports asynchronous serial communication with selectable baud rates. The user can adjust baud rates from 300 to 19,200 bps. It handles 7 or 8 data bits with configurable parity and stop bits. The unit buffers incoming data for reliable message handling. It supports both polled and interrupt-driven data transfer methods.
Installation and System Integration
You can install this module into any available slot in the NR series rack. Align the module carefully and press it into the backplane connector. Connect the serial cable to the 9-pin D-sub port on the front panel. Configure the communication parameters to match the connected device. Verify the baud rate and parity settings before data exchange.
Environmental Compliance
This module carries CE marking for industrial use. It complies with RoHS environmental directives. The module suits standard control cabinet installations with IP20 protection.
Details
| Weight | 1.4 kg |
|---|---|
| Dimensions | 127 × 254 × 203 mm |
