This remote module extends I/O connectivity to distant field locations within a control network. It integrates seamlessly into the Fuji Electric Micro-SX and SPH series PLC systems. The unit combines digital and analog signal processing in a compact form factor. Users can place I/O closer to sensors and actuators for reduced wiring costs.

I/O Configuration and Channel Specifications

This module features a mixed I/O configuration for versatile field connectivity. It provides 8 digital inputs operating at 24 V DC for sensor and switch monitoring. The unit also includes 7 relay outputs rated at 2 A per channel for actuator control. Each relay output handles 250 V AC or 30 V DC loads for flexible switching. The inputs accept signals from 0 V to 30 V with fast response times. Furthermore, the module offers 1 analog output for proportional control applications.

Communication Architecture and Network Integration

The NR1TY-08R07DT communicates with the master controller via the T-Link remote bus. This dedicated protocol ensures deterministic data exchange for real-time control. The module supports a maximum transmission distance of 200 m between stations. Users can connect up to 31 remote modules on a single T-Link network. This architecture enables distributed control across large production facilities. Consequently, engineers can design scalable systems with minimal wiring complexity.

Response Performance and Update Times

This remote module delivers rapid I/O scanning for time-sensitive applications. Digital input response times remain under 1 ms for fast event detection. Relay output switching occurs within 10 ms for reliable actuator control. The analog output updates every 5 ms for smooth process regulation. This performance suits packaging machinery, conveyor systems, and simple positioning tasks. Moreover, the module buffers data during communication interruptions for added reliability.

Energy Consumption and Power Requirements

The module draws 30 mA at 24 V DC from the remote bus power supply. This low consumption minimizes the load on the network power source. The unit also accepts an external 24 V DC supply for output relay coils. Power dissipation remains below 3 W under full operational load. Natural convection cooling maintains safe temperatures across all components. Consequently, the operating range spans 0 °C to 55 °C for standard factory environments.

Diagnostic Indicators and Status Monitoring

Six front-panel LEDs provide clear visual feedback for operators and technicians. A green “Power” LED confirms the presence of supply voltage. A “Run” LED indicates normal communication with the master controller. A red “Error” LED signals network faults or module malfunctions. Individual LEDs show the status of each digital input and output channel. These indicators simplify troubleshooting without requiring programming software.

Mounting Flexibility and Environmental Tolerance

The module features a compact housing suitable for DIN rail or direct mounting. Its small footprint fits into tight control cabinets and junction boxes. The unit carries an IP20 rating for protection against solid objects. Humidity tolerance spans 10% to 90% without condensation issues. Furthermore, the module resists vibration up to 0.75 g for industrial durability. This robust design suits automotive assembly, material handling, and food processing applications.
