Reliable Signal Distribution and Termination

The FUJI NR1TW-16T65DT terminal module provides organized signal distribution for industrial control systems. This module consolidates field wiring from sensors and actuators into a structured connection interface. Maintenance teams appreciate this unit for its clear labeling and accessible termination points.

Electrical Specifications and Connection Capacity

This terminal module features 16 spring-clamp termination points with a current rating of 10 A per position. The unit accepts solid or stranded wires from 0.2 mm² to 2.5 mm² without requiring special tools. A built-in jumper bar allows commoning of adjacent terminals for group power distribution. Furthermore, the module includes an integrated test point for each connection, simplifying signal verification.

Connection Technology and Handling

The spring-clamp mechanism ensures gas-tight connections that resist vibration and thermal cycling. Users can insert or remove wires quickly using a standard screwdriver or the integrated push-button. The connector accepts both solid and stranded conductors with ferrule termination. This design significantly reduces installation time compared to traditional screw terminals.

Labeling and Identification Features

This terminal module includes a transparent protective cover with a label holder for circuit identification. The housing also features a marking strip for permanent component designations. These labeling options simplify troubleshooting and ensure compliance with safety standards. Maintenance personnel can easily trace wires back to their field devices.

Applications and System Integration

You can use this terminal module in control cabinets, junction boxes, and field termination enclosures. The unit works with all automation systems, including PLCs, drives, and instrumentation. Multiple modules can mount side by side on the same DIN rail for extensive signal distribution. For high-density applications, you can combine this unit with other FUJI terminal blocks.

Safety and Compliance Standards

The FUJI NR1TW-16T65DT meets UL 1059 and EN 60947-7-1 standards for terminal block applications. The polyamide housing offers excellent electrical insulation and resistance to common industrial chemicals. A finger-safe design prevents accidental contact with live parts during operation. Always ensure proper wire stripping lengths and insertion depths for reliable connections.
