Technical Overview
The NR1SW-16T65DT remote I/O module from Fuji Electric provides distributed input capabilities for industrial automation systems. This module features an 8-point source input configuration for connecting sensors, switches, and other field devices. The RS-485 communication interface enables reliable data exchange with the host controller. Furthermore, its compact design saves valuable panel space.
Key Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Fuji Electric |
| Model Number | NR1SW-16T65DT |
| Product Type | Remote I/O Module |
| Input Configuration | 8-point Source Input |
| Power Supply | 24V DC ±10% |
| Current Consumption | 100 mA max |
| Communication Interface | RS-485 |
| Protection Rating | IP20 |
| Mounting Type | DIN Rail Mountable |
| Dimensions (W x H x D) | 120 mm x 80 mm x 50 mm |
| Weight | Approx. 300 g |
| Operating Temperature | -10°C to +60°C |
| Status | Current product |
Efficient Input Processing
The NR1SW-16T65DT accepts digital signals from eight independent input sources. Each channel processes signals from devices such as proximity sensors and pushbuttons. The module transmits this data to the host controller via the RS-485 network.
Communication and Network Integration
The RS-485 interface supports multi-drop configurations for connecting multiple remote modules. This network topology reduces wiring complexity in large automation systems. Consequently, engineers can distribute I/O points across a factory floor with minimal cabling.
Mechanical Design and Installation
The unit frame measures 148mm x 50mm x 40mm, allowing for standardized panel design. The DIN rail mounting system ensures quick installation without special tools. The IP20 protection rating safeguards the internal electronics from solid objects larger than 12mm.
Application Environments
This remote module suits a wide range of industrial control applications. It excels in distributed I/O systems, machine control, and process monitoring. The module’s robust design ensures reliable performance across various manufacturing sectors.
Details
| Weight | 0.7 kg |
|---|---|
| Dimensions | 2.5 × 20.3 × 15.2 mm |
