This terminal block provides a reliable connection point for field devices and control systems. It organizes and secures multiple signal lines within industrial control panels. The Fuji NR1LX-1606DT accommodates sixteen independent wire connections for dense I/O applications. This design simplifies cable management and accelerates the overall installation process.
Physical Dimensions and Mounting Specifications
This terminal block measures 160 millimeters in width, 45 millimeters in depth, and 50 millimeters in height. The unit weighs approximately 0.35 kilograms for lightweight panel integration. It mounts directly onto a standard 35-millimeter DIN rail using the integrated clip mechanism. The housing consists of high-strength polyamide material for excellent mechanical durability. Moreover, the translucent cover provides clear visual access to all wiring points.
Connection Points and Wire Capacity
The Fuji NR1LX-1606DT features sixteen spring-clamp terminals arranged in a single row. Each terminal accepts solid or stranded copper wires from 0.14 to 2.5 square millimeters. The spring-clamp design ensures a gas-tight connection that resists vibration loosening. Every terminal includes a test point for convenient signal measurement. The module also provides two additional earth terminals for grounding requirements.
Electrical Ratings and Performance
This terminal block handles a maximum continuous current of 10 amperes per connection point. The rated insulation voltage reaches 500 volts AC for robust isolation performance. Contact resistance remains below 5 milliohms for minimal power loss. The unit withstands impulse voltages up to 4 kilovolts for surge protection. These electrical characteristics guarantee reliable signal integrity in harsh factory floors.
Component Architecture and Build Quality
The Fuji NR1LX-1606DT contains 18 individual components including terminal springs and busbars. The current-carrying parts use tin-plated copper alloy for superior conductivity. Each spring mechanism undergoes a 50,000-cycle durability test for long service life. The insulating housing meets UL 94 V-0 flammability standards for fire safety.
Installation and Wire Preparation
Engineers can install this terminal block quickly without any specialized tools. Stripping the wire insulation to 8 millimeters achieves the optimal clamping force. The color-coded test points simplify periodic continuity checks. We recommend using ferrule connectors for stranded wires to enhance connection integrity.
Technical Data Summary
| Parameter | Specification |
|---|---|
| Brand | Fuji |
| Model | NR1LX-1606DT |
| Product Type | Terminal Block |
| Dimensions (W x D x H) | 160 mm x 45 mm x 50 mm |
| Weight | 0.35 kg |
| Number of Terminals | 16 (spring-clamp type) |
| Wire Size Range | 0.14 to 2.5 mm² |
| Earth Terminals | 2 additional |
| Continuous Current Rating | 10 A per terminal |
| Insulation Voltage | 500 V AC |
| Contact Resistance | < 5 mΩ |
| Impulse Withstand Voltage | 4 kV |
| Housing Material | Polyamide, UL 94 V-0 |
| Mounting | 35 mm DIN rail |
| Component Count | 18 parts |
| Conductor Material | Tin-plated copper alloy |
System Integration and Maintenance
This terminal block works seamlessly with most industrial control and automation systems. Its modular design allows easy replacement of individual connection points. Consequently, the Fuji NR1LX-1606DT provides a cost-effective wiring solution for panel builders.
Details
| Weight | 0.35 kg |
|---|---|
| Dimensions | 160 × 45 × 50 mm |
