Core Technical Specifications
This digital output module delivers reliable switching for actuators and indicators in your control system. We engineered the NP1Y32U09P1 to provide efficient and protected control for demanding field applications.
| Parameter | Specification |
|---|---|
| Product Type | Digital Output Module |
| Dimensions | 120 mm x 100 mm x 75 mm (W x H x D) |
| Weight | 0.45 kg |
| Supply Voltage | 24 V DC nominal (range: 20.4 V to 28.8 V) |
| Power Consumption | 5 W typical |
| Output Channels | 32 solid-state outputs |
| Output Current | 0.5 A per channel, 8 A total |
| Output Type | Sinking (NPN), transistor-based |
| Protection Features | Short-circuit and over-temperature protection |
| Switching Frequency | 100 Hz maximum (resistive load) |
| On-State Voltage | ≤ 1.0 V at 0.5 A load |
| Leakage Current | < 0.1 mA in off-state |
| Isolation | 500 V AC (field-to-logic) |
| Diagnostics | 32 green LEDs for per-channel status |
| Response Time | 0.8 ms typical |
| Operating Temp. | 0 °C to 55 °C |
| Mounting | DIN-rail or panel-mounted |
| Certifications | CE, UL, and CSA approved |
High-Density Output Configuration
The NP1Y32U09P1 provides 32 solid-state outputs in a space-efficient housing for maximum channel density. This design controls a large number of field devices while minimizing cabinet space requirements. Each channel sources 0.5 A for driving solenoids, relays, and LED indicators. The total module load of 8 A accommodates simultaneous operation across all channels.
Fast and Efficient Performance
This output module achieves a 100 Hz maximum switching frequency for high-speed control applications. The fast 0.8 ms response time ensures immediate output activation for time-critical processes. The low on-state voltage below 1.0 V minimizes power dissipation and reduces cabinet heating. The minimal leakage current prevents unintended actuation of sensitive loads.
Comprehensive Output Protection
The NP1Y32U09P1 integrates short-circuit protection and over-temperature shutdown on every channel. These protective circuits disconnect faulty outputs automatically to prevent catastrophic module damage. The outputs recover automatically after fault clearance without requiring manual reset. This robust protection ensures reliable operation even under adverse wiring conditions.
Superior Isolation and Diagnostic Visibility
This digital output module provides 500 V AC isolation between field outputs and backplane logic. This isolation safeguards the control system from ground loops and voltage transients. The 32 green LEDs provide immediate visual status indication for each channel. This comprehensive diagnostic visibility simplifies troubleshooting and reduces system downtime.
Durable Construction for Industrial Environments
The NP1Y32U09P1 features a compact 120 x 100 x 75 mm form factor for efficient cabinet utilization. The 0.45 kg weight ensures secure mounting on DIN rails or panels. The module operates reliably across a 0 °C to 55 °C temperature range. The rugged construction resists vibration, humidity, and electrical noise for long-term reliability.
Details
| Weight | 0.45 kg |
|---|---|
| Dimensions | 120 × 100 × 75 mm |
