Core Technical Specifications
This digital output module drives actuators with high-density switching capability for automation systems. We engineered the NP1Y32T09P1-A to deliver reliable and efficient control for demanding field applications.
| Parameter | Specification |
|---|---|
| Product Type | Digital Output Module |
| Dimensions | 120 mm x 100 mm x 75 mm (W x H x D) |
| Weight | 0.42 kg |
| Supply Voltage | 24 V DC nominal (range: 20.4 V to 28.8 V) |
| Power Consumption | 4.5 W typical |
| Output Channels | 32 solid-state outputs |
| Output Current | 0.5 A per channel, 8 A total |
| Output Type | Sourcing (PNP), transistor-based |
| Protection Features | Short-circuit and over-temperature protection |
| Switching Frequency | 100 Hz maximum (resistive load) |
| On-State Voltage | ≤ 1.0 V at 0.5 A load |
| Leakage Current | < 0.1 mA in off-state |
| Isolation | 500 V AC (field-to-logic) |
| Diagnostics | 32 green LEDs for per-channel status |
| Response Time | 1 ms typical |
| Operating Temp. | 0 °C to 55 °C |
| Mounting | DIN-rail or panel-mounted |
| Certifications | CE, UL, and CSA approved |
High-Density Output Configuration
The NP1Y32T09P1-A offers 32 solid-state outputs in a compact housing for space-saving installations. This high-density design controls numerous field devices without requiring multiple modules. Each channel sources up to 0.5 A for driving solenoids, relays, and indicator lamps. The total module load of 8 A supports simultaneous operation of multiple actuators.
Fast and Efficient Switching
This output module achieves a maximum switching frequency of 100 Hz with resistive loads. This speed supports rapid cycling applications such as pulsed heating or high-speed indexing. The low on-state voltage of 1.0 V minimizes power dissipation and heat generation. The minimal leakage current below 0.1 mA prevents false triggering of sensitive loads.
Comprehensive Protection and Diagnostics
The NP1Y32T09P1-A integrates short-circuit and over-temperature protection on every output channel. These protective circuits automatically disconnect faulty outputs to prevent module damage. After clearing the fault, the output restores normal operation without manual intervention. The 32 green LEDs provide instant visual feedback on each channel’s active status for simplified troubleshooting.
Reliable Electrical Isolation
This digital output module provides 500 V AC isolation between field outputs and logic circuitry. This isolation protects the control system from ground loops and transient overvoltages. The design also eliminates noise coupling from field wiring, ensuring stable system performance. This robust isolation makes the NP1Y32T09P1-A suitable for electrically harsh environments.
Compact and Durable Design
The NP1Y32T09P1-A features a compact 120 x 100 x 75 mm form factor for efficient cabinet space utilization. The 0.42 kg weight ensures secure mounting on DIN rails or panels. The module operates reliably across a 0 °C to 55 °C temperature range. The rugged construction resists vibration and humidity for long-term reliability in factory environments.
Details
| Weight | 0.42 kg |
|---|---|
| Dimensions | 120 × 100 × 75 mm |
