High-Density Input for NP1 Systems

The Fuji NP1X3206-A delivers 32 digital input channels in a compact single-width housing. This module accepts 24 V DC signals from sensors, pushbuttons, and selector switches . It draws 7 mA per channel for reliable and consistent signal detection . Consequently, this high-density module suits large-scale monitoring and control applications.

Input Circuit Design and Isolation

The NP1X3206-A uses opto-isolation to separate field inputs from the PLC backplane . This isolation protects against electrical noise and transient voltage spikes . Each input channel includes a filter circuit for contact debouncing . Furthermore, a green LED indicator shows the status of every individual channel .

Response and Performance Characteristics

The module processes input signals with a response time under 5 milliseconds . This rapid response supports high-speed counting and positioning applications . The Fuji NP1X3206-A provides diagnostic data through the system registers . Its input impedance matches standard 24 V DC sourcing outputs .

Physical and Mounting Specifications

The module weighs 0.3 kilograms and occupies one NP1 standard slot . It plugs directly into the backplane without requiring external power wiring . The NP1X3206-A uses a 40-pin connector for field input terminations . Its high channel density maximizes I/O capacity per rack .

Electrical and Environmental Parameters

This input module consumes 80 mA from the 24 V DC supply . It operates reliably between 0 and 55 °C ambient temperature . The Fuji NP1X3206-A stores from -25 to 70 °C during transportation . It meets standard industrial EMC and vibration specifications .
