Technical Specifications
| Parameter | Details |
|---|---|
| Product Type | Programmable Logic Controller (CPU Module) |
| Compatibility | Fuji MICREX-SX Series SPH |
| Processor Speed | 32 MHz (32-bit RISC) |
| Program Memory | 64 KB RAM |
| User Program Storage | 128 KB Flash Memory |
| Data Memory | 32 KB RAM |
| Digital I/O Capacity | 512 inputs / 512 outputs (maximum) |
| Analog I/O Capacity | 128 inputs / 128 outputs (maximum) |
| Communication Ports | 1 x RS-232C (programming), 1 x RS-485 |
| Protocol Support | Modbus RTU, Fuji SX Bus |
| Dimensions (H x W x D) | 100 mm x 60 mm x 95 mm |
| Weight | 0.45 kg |
| Power Consumption | 3.5 W typical |
| Current Draw (5 VDC) | 300 mA |
| Battery Backup | 3.0 V lithium (CR2032) |
| Battery Life | 3 years typical |
| Operating Temperature | 0 °C to 55 °C |
| Storage Temperature | –25 °C to +70 °C |
| Relative Humidity | 30 % to 85 % (non-condensing) |
| Protection Class | IP20 |
| Certifications | CE, UL, CSA |
Processing Power and Memory Architecture
The NP1BS-13 programmable logic controller delivers dependable control performance for medium-scale automation systems. This CPU module operates at 32 MHz using a 32-bit RISC architecture, ensuring fast execution of complex logic and mathematical operations. The unit provides 64 KB of program memory and 32 KB of data memory, with an additional 128 KB of flash storage for non-volatile program retention. Consequently, users can deploy sophisticated control strategies without worrying about memory constraints.
I/O Expansion Capabilities
This controller supports extensive I/O expansion, accommodating up to 512 digital points and 128 analog channels through the MICREX-SX backplane. The NP1BS-13 automatically detects connected modules during power-up, simplifying system configuration and reducing commissioning time. Furthermore, users can mix digital, analog, and specialty modules freely, tailoring the system to specific application requirements.
Communication and Integration
The NP1BS-13 includes an RS-232C port for direct connection to programming software, enabling fast application downloads and online debugging. An additional RS-485 port supports Modbus RTU communication, facilitating integration with HMIs, drives, and remote I/O devices. Additionally, the module supports the Fuji SX Bus protocol, ensuring seamless interoperability with other MICREX-SX family components.
Physical and Power Specifications
Weighing 0.45 kg and measuring 100 mm x 60 mm x 95 mm, the NP1BS-13 occupies a single slot in the SPH rack system. This module draws 300 mA from the 5 VDC backplane supply, consuming 3.5 W during normal operation. A replaceable CR2032 lithium battery preserves real-time clock data and memory contents for approximately three years, ensuring reliable operation during power interruptions.
Details
| Weight | 0.41 kg |
|---|---|
| Dimensions | 128 × 38 × 100 mm |
