Product Overview
The FUJI NP1AXH4-MR analog input module delivers precise analog signal acquisition for industrial automation and process control applications. It converts field signals into reliable controller data, allowing accurate monitoring throughout continuous production operations.
Moreover, the compact housing optimizes control cabinet space while supporting convenient installation inside compatible Fuji PLC systems. The integrated backplane connector ensures stable communication and simplifies system expansion without increasing wiring complexity.
Additionally, the module combines industrial-grade electronic components with an optimized circuit layout to improve measurement accuracy. Internal filtering technology reduces electrical noise, helping controllers receive consistent analog signals under demanding operating conditions.
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | FUJI |
| Model | NP1AXH4-MR |
| Product Category | Analog Input Module |
| Input Type | Analog Input |
| Number of Input Channels | 4 Channels |
| Supported Signal Types | Voltage and Current Analog Signals |
| Installation Method | PLC Rack Installation |
| Interface | High-density Backplane Connector |
| Signal Processing | High-precision Analog-to-Digital Conversion |
| Circuit Structure | Multi-layer Industrial PCB |
| Component Configuration | Precision ICs, operational amplifiers, resistors, capacitors, protection circuitry, LED indicators |
| Energy Storage | Integrated capacitors for voltage stabilization |
| Housing Material | Flame-retardant Industrial Plastic |
| Cooling Method | Natural Air Convection |
| Dimensions | Approx. 130 × 35 × 120 mm |
| Weight | Approx. 0.30 kg |
| Operating Environment | Industrial Automation and Process Control |
Key Features
The FUJI NP1AXH4-MR supports four independent analog input channels, allowing simultaneous monitoring of multiple industrial process variables. Furthermore, precision analog conversion technology improves measurement consistency across long operating periods.
In addition, industrial-grade connectors maintain secure electrical connections throughout demanding production environments. Diagnostic LED indicators provide clear operating status, enabling technicians to complete maintenance tasks more efficiently.
The optimized circuit architecture minimizes signal interference, while integrated protection circuitry improves long-term operational reliability. Energy storage capacitors also stabilize internal voltage during signal fluctuations, ensuring dependable analog data acquisition for automation systems.
Industrial Applications
Engineers frequently install the FUJI NP1AXH4-MR in process automation, chemical production, water treatment, power generation, manufacturing equipment, and industrial monitoring systems. Additionally, the module receives analog signals from pressure transmitters, temperature sensors, flow meters, level instruments, and other field devices while delivering accurate data to PLC controllers.
Advantages for Industrial Automation
Compact dimensions simplify panel integration, while high-precision analog processing improves overall control performance. Consequently, this module helps engineers increase measurement accuracy, enhance system stability, and support reliable industrial automation across demanding operating environments.
Details
| Weight | 0.7 kg |
|---|---|
| Dimensions | 2.5 × 20.3 × 15.2 mm |
