This basic unit provides an all-in-one controller solution for compact machinery applications. It integrates seamlessly into the Fuji Electric NB series programmable logic controller family. The unit combines processor, power supply, and I/O in a single housing. Users can implement relay logic, timing sequences, and basic counting functions efficiently.

Integrated I/O Configuration and Channel Specifications

This basic unit features a fixed I/O configuration for direct field device connectivity. It provides 24 digital inputs operating at 24 V DC for sensor and switch monitoring. The unit also includes 16 relay outputs rated at 2 A per channel for actuator control. Each relay output handles 250 V AC or 30 V DC loads for versatile switching. The inputs accept signals from 0 V to 30 V with adjustable filtering options. Consequently, users can connect proximity sensors, limit switches, and pilot lamps directly.

Programming Capabilities and Memory Resources

The NB1U40R stores user programs in 8 KB of internal flash memory. Data memory reaches 4 KB for variables, timers, and counter values. The unit executes ladder logic instructions with a speed of 1,000 instructions per millisecond. This performance supports basic sequential control and interlocking logic effectively. The built-in real-time clock enables time-based scheduling and event logging. Furthermore, users can store up to 64 timers and 64 counters simultaneously.

Communication Interface and Programming Connectivity

This basic unit includes an RS-232C port for programming and HMI communication. Users connect the module to a PC via a standard programming cable. The port also supports connection to operator panels and simple displays. This interface enables program uploads, downloads, and online monitoring. Additionally, the unit supports data exchange with third-party devices using custom protocols. This connectivity simplifies system integration and commissioning procedures.

Power Supply and Energy Efficiency

The unit accepts a 100 V to 240 V AC power supply for global compatibility. It draws approximately 200 mA at 24 V DC for internal logic operations. Power dissipation remains below 10 W under full operational load. The module includes built-in surge protection for reliable operation. Additionally, it withstands brief power interruptions up to 10 ms without resetting. This ride-through capability prevents nuisance shutdowns during minor grid fluctuations.

Diagnostic Indicators and Status Monitoring

Eight front-panel LEDs provide clear visual feedback for operators and technicians. A green “Power” LED confirms the presence of supply voltage. A “Run” LED indicates normal program execution and scanning. A red “Error” LED signals program faults or hardware malfunctions. Individual LEDs show the status of output channels for quick verification. These indicators simplify troubleshooting without requiring programming software.

Mechanical Durability and Environmental Resistance

The unit carries an IP20 rating for protection against solid objects. Its robust housing fits into standard electrical cabinets with limited space. The operating temperature ranges from 0 °C to 55 °C for reliable performance. Humidity tolerance spans 10% to 90% without condensation issues. Furthermore, the unit resists vibration up to 0.75 g from 10 to 57 Hz. This rugged construction suits packaging machines, conveyor systems, and simple assembly stations.
