This programmable controller module serves as a compact solution for small to mid-sized automation systems. It functions as an input unit within the Fuji FTU Series, providing reliable digital signal acquisition. Engineers choose this module for its 32-channel input capacity and efficient design. Its integration capability makes it ideal for upgrading legacy MICREX-F systems.

Input Architecture and Signal Processing

The Fuji FTU155C provides 32 digital input points for connecting field devices and sensors. Its input channels accept 100–120 VAC signals at 50/60 Hz for versatile industrial compatibility. The input response time measures 10 ms for reliable signal detection and processing. This module uses terminal block wiring for straightforward and secure field connections. Furthermore, the unit supports the NP1X1610 replacement configuration for MICREX-F to MICREX-SX migrations.

Physical Specifications and Installation Options

The Fuji FTU155C measures 12.0 cm in height, 6.5 cm in width, and 10.5 cm in depth. Its weight reaches approximately 0.28 kg for straightforward handling during installation. The compact footprint saves valuable panel space in control cabinets. This unit features integrated mounting tabs for either DIN rail or panel installation. LED indicators on the front panel provide immediate visual feedback for power and I/O status.

System Integration and Compatibility

This module integrates with Fuji FPU series PLCs including FPU080H, FPU120S, and FPU120H models. It also serves as the FTU155C to NP1X1610 conversion path for system upgrades. The specific conversion adapter and cable types apply for replacing MICREX-F with MICREX-SX systems. Consequently, engineers can modernize existing installations with minimal wiring changes.

Key Technical Specifications

The table below summarizes the critical parameters for the Fuji FTU155C.
