The FUJI FEH034 is a high-performance home hybrid inverter for residential and light commercial solar energy systems. This unit seamlessly integrates solar power, battery storage, and grid electricity for optimized energy management. It supports three independent MPP trackers for maximum solar harvest from different panel orientations . Furthermore, the inverter achieves a maximum efficiency of 98.2% with a European efficiency rating of 97.5% .
Integrated Battery Storage and Backup Function
This hybrid inverter includes integrated battery storage capability for uninterrupted power during grid outages. The FUJI FEH034 provides a black start function and supports unbalanced load operation in emergency power mode . It can deliver up to 5 kW per phase during backup operation. Consequently, this ensures critical appliances remain operational when the grid fails.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Fenecon (Fuji Electric) |
| Model | FUJI FEH034 |
| Product Type | Home Hybrid Inverter |
| Nominal AC Power | 15,000 W (15 kW) |
| Max. DC Input Power | 22,500 Wp |
| Max. DC Voltage | 1,000 V |
| DC Voltage Range | 120 V to 850 V |
| Max. DC Current | 16 A |
| Number of MPP Trackers | 3 |
| Grid Connection | 3-phase |
| Nominal AC Voltage | 400 V |
| Max. Efficiency | 98.2% |
| Euro Efficiency | 97.5% |
| Dimensions (W x H x D) | 496 x 460 x 221 mm |
| Weight | 25 kg |
| IP Protection Class | IP 55 |
| Communication Interfaces | Ethernet (LAN), RS 485 |
| Warranty | 10 years |
Advanced Monitoring and Communication
This inverter provides smart monitoring and control capabilities through a mobile application . The FUJI FEH034 supports Ethernet and RS 485 interfaces for seamless system integration . It includes an integrated energy meter with measuring transformers for accurate grid connection point monitoring . Additionally, the module complies with CE and VDE certification standards .
Installation and Environmental Resilience
The FUJI FEH034 features a compact, transformerless design for easy wall or floor mounting . Its IP 55 enclosure rating provides excellent protection against dust and water ingress . The unit operates without a cooling fan, ensuring silent operation and higher reliability. Moreover, the surge protection device (Type II) safeguards the system from voltage spikes .
Details
| Weight | 0.7 kg |
|---|---|
| Dimensions | 2.5 × 20.3 × 15.2 mm |
