This processor unit delivers exceptional computational power for mid-range automation tasks. It handles complex logic operations and motion control sequences with remarkable efficiency. The module integrates seamlessly into existing Fuji Electric automation architectures. Its advanced processing engine reduces scan times significantly for time-critical processes.
Core Processing Capabilities and Memory Architecture
The unit features a 32-bit RISC processor running at 100 MHz clock speed. It provides 128 KB of user program memory for extensive control applications. The system includes 16 KB of retentive data memory for critical variables. An additional 4 KB of flash memory stores system configuration parameters permanently.
| Parameter | Specification |
|---|---|
| Model | NV1P-082 |
| Processor Type | 32-bit RISC, 100 MHz |
| Program Memory | 128 KB user logic |
| Data Memory | 16 KB retentive, 4 KB flash |
| Processing Speed | 0.08 µs per bit instruction |
| Digital I/O Capacity | Up to 256 points local |
| Analog I/O Capacity | Up to 64 channels |
| High-Speed Counters | 4 channels, 50 kHz each |
| Pulse Outputs | 2 channels, 100 kHz |
| Communication Ports | 1 x RS-232C, 1 x RS-485 |
| Power Supply | 24 V DC ±10%, 300 mA |
| Power Consumption | 7.2 W maximum |
Mechanical Dimensions and Installation Details
This processor unit measures 110 mm in height, 90 mm in width, and 65 mm in depth. Its robust housing weighs approximately 0.52 kg and resists industrial contaminants. You can mount the device on a standard 35 mm DIN rail or use direct screw fixing. The front-facing connector layout simplifies cable routing and maintenance access.
Built-in Communication and Expansion Interfaces
The NV1P-082 includes two onboard serial ports for versatile connectivity. One RS-232C port supports programming and HMI communication simultaneously. The RS-485 port enables multi-drop networking with up to 31 slave devices. You can also expand system I/O using the dedicated expansion bus interface.
Counter and Pulse Output Features
Four high-speed counter inputs capture signals up to 50 kHz each. These counters support incremental encoder feedback for precise positioning tasks. Two pulse output channels generate 100 kHz signals for stepper motor control. Each channel provides independent direction and pulse train outputs.
Data Retention and System Reliability
An internal supercapacitor maintains the real-time clock for approximately 7 days. This capacitor also preserves retentive data during power-off conditions without a battery. The module monitors its internal temperature and voltage levels continuously. It triggers a warning output when operating conditions deviate from specifications.
Details
| Weight | 0.45 kg |
|---|---|
| Dimensions | 120 × 100 × 75 mm |
