This output module drives a wide range of field actuators and indicator devices. It converts digital control signals into robust output currents for industrial equipment. The unit ensures precise and repeatable operation of valves, motors, and alarms. Its modular design facilitates simple installation and quick replacement in the field.

Output Channel Configuration and Electrical Ratings

The module provides sixteen individual output channels for versatile load control. Each channel features a solid-state relay for silent and fast switching operations. The outputs handle continuous currents up to 2 A per point. All channels share a common return terminal for simplified wiring layouts.

Physical Dimensions and Mounting Specifications

This output module measures 110 mm in height, 65 mm in width, and 85 mm in depth. Its durable enclosure weighs approximately 0.32 kg for easy handling. You can mount the unit on a standard 35 mm DIN rail inside any control cabinet. The module occupies only 65 mm of panel width for space-efficient layouts.

Connector Interface and Wiring Arrangements

The FTU223B includes a 34-pin ribbon cable connector for signal input. A separate 16-position screw terminal block provides all output connections. Each terminal accepts wire sizes from 0.5 mm² to 2.5 mm². You can access all wiring points from the front panel for convenient maintenance.

Channel Status Monitoring and Diagnostics

Sixteen high-brightness LEDs indicate the ON/OFF state of each output channel. The module also provides a common power LED for supply voltage verification. An internal fuse protects the unit against over-current conditions. You can reset the protection circuit by cycling the power supply.

Load Protection and Thermal Management

Each output includes built-in short-circuit protection for reliable operation. The module also incorporates over-temperature shutdown to prevent component damage. A heatsink dissipates heat efficiently during high-current operation. You should maintain adequate airflow around the module for optimal performance.

Compatibility and System Integration

This output module interfaces directly with Fuji Electric PLC systems. It also works with third-party controllers using standard 24 V DC logic signals. The unit supports both sinking and sourcing output configurations. You can mix this module with other I/O types in the same rack.
