This CPU module integrates a high-speed processor with onboard flash storage for reliable program execution. It delivers seamless control logic processing for complex industrial automation systems. The module supports a wide range of I/O configurations to meet diverse application requirements.
Technical Specifications and Physical Attributes
The module measures 130 mm in height, 50 mm in width, and 95 mm in depth. Its compact housing weighs approximately 0.45 kg, which simplifies installation in crowded control cabinets. The unit features a 40-pin ribbon cable connector for high-speed data transfer. It also includes a removable terminal block for discrete I/O wiring.
| Parameter | Specification |
|---|---|
| Model | FNC130A-C10 |
| Processor Speed | 80 MHz, 32-bit RISC |
| Flash Memory | 8 MB onboard, non-volatile |
| Program Capacity | 64 KB user logic |
| Digital Inputs | 16 points, 24 V DC sink/source |
| Digital Outputs | 12 points, relay type, 2 A per point |
| Analog Channels | 2 inputs, 0–10 V DC, 12-bit resolution |
| Communication Port | RS-485, Modbus RTU protocol |
| Power Supply | 24 V DC ±10%, 250 mA max |
| Operating Temperature | 0 °C to 55 °C |
| Storage Temperature | -25 °C to 75 °C |
Memory Architecture and Data Retention
This module stores user programs and system parameters in its 8 MB flash memory. The non-volatile design retains all data during unexpected power loss without a backup battery. It also provides 4 KB of retentive memory for critical process variables.
Connectivity and Expansion Options
The unit includes one RS-485 port for connecting to HMIs and drives. This port supports the Modbus RTU master-slave communication for network integration. You can expand the I/O capacity using the built-in expansion interface. This interface allows you to attach up to three additional I/O modules.
Power Consumption and Environmental Resilience
The module draws a maximum current of 250 mA from a 24 V DC supply. It consumes only 6 W of power under full load, ensuring energy-efficient operation. Its robust design withstands vibration up to 5 G and operates reliably in humid environments.
Installation and Mounting Details
The module mounts directly onto a standard 35 mm DIN rail inside the enclosure. The locking mechanism secures the unit firmly without additional hardware. You can access all wiring points from the front panel for simplified maintenance.
Details
| Weight | 0.42 kg |
|---|---|
| Dimensions | 120 × 100 × 75 mm |
