High-Power Switching Solution for Industrial Drives
The ABB FS450R17KE3/AGDR-71C 3ABD68444217-D combines a 1700V/450A six-pack IGBT module with an intelligent gate driver board . This integrated system delivers precise switching control and comprehensive protection for demanding power conversion applications. The IGBT section utilizes a six-pack three-phase bridge configuration with six transistors and anti-parallel freewheeling diodes . The AGDR-71C driver board provides isolated gate drive signals and monitors critical parameters like overcurrent and overtemperature .
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | IGBT Power Module with Gate Driver |
| Order Number | FS450R17KE3/AGDR-71C 3ABD68444217-D |
| Collector-Emitter Voltage (VCES) | 1700 V |
| DC Collector Current (IC) | 450 A at 25°C case temperature |
| Peak Collector Current | 900 A (10ms pulse) |
| Power Dissipation | 2250 W typical |
| Saturation Voltage (VCEsat) | 2.1 V typical at 450 A, 25°C |
| Gate-Emitter Voltage | ±20 V |
| Gate Drive Voltage (AGDR-71C) | +15 V / -7 V DC |
| Driver Supply Voltage | 24 V DC external |
| Protection Features | DESAT overcurrent, overtemperature, gate voltage monitoring |
| Switching Frequency | Up to 20 kHz (depends on cooling) |
| Thermal Resistance (Rth(j-c)) | 0.05 K/W per IGBT |
| Isolation Voltage | 4000 V RMS (1 minute test) |
| Junction Temperature | -40°C to +150°C |
| Dimensions (L x W x H) | 160 mm x 65 mm x 20 mm |
| Weight | Approximately 2.8 kg |
| Cooling Method | Baseplate water-cooling or forced air |
| Mounting | Screw-mount baseplate |
| Country of Origin | Sweden |
Application and System Integration
Engineers commonly deploy the ABB FS450R17KE3/AGDR-71C 3ABD68444217-D in medium-voltage variable frequency drives and renewable energy inverters . This module suits motor control applications up to 400 kW, including fans, pumps, and mill drives. It also supports photovoltaic inverters in 1500 V solar systems and energy storage converters for grid-level battery management . The integrated gate driver reduces external component count, simplifying system design and improving overall reliability.
