Core Technical Specifications of the Yokogawa AAT145-S00 Module
The Yokogawa AAT145-S00 handles thermocouple and millivolt signals with high accuracy. This module provides 8 isolated input channels for simultaneous temperature measurements. Each channel accepts types B, E, J, K, N, R, S, and T thermocouples. You can also configure any channel for ±10 mV, ±50 mV, or ±100 mV ranges. The device achieves 20-bit resolution for fine temperature readings. A built-in cold junction compensator eliminates external reference needs. This design reduces wiring complexity and installation time.
| Parameter | Specification |
|---|---|
| Input Channels | 8 isolated differential inputs |
| Thermocouple Types | B, E, J, K, N, R, S, T |
| mV Ranges | ±10 mV, ±50 mV, ±100 mV |
| Resolution | 20 bits |
| Accuracy | ±0.05% of reading |
| Input Impedance | 1 MΩ minimum |
| Cold Junction Compensation | Built-in, automatic |
Physical Dimensions and Connectivity Features
The Yokogawa AAT145-S00 weighs approximately 0.35 kilograms for easy handling. Its dimensions measure 12.5 cm in height and 4.5 cm in width. The front panel includes 8 LED indicators for channel status monitoring. Each channel uses a screw-type terminal block for secure wiring. The module stores no internal energy for safe hot-swapping. You will find a 24-pin backplane connector for system integration. The enclosure meets IP30 protection standards for control room use.
Environmental Ratings and Manufacturer Information
This input module operates reliably from -10°C to 55°C ambient temperatures. The Yokogawa AAT145-S00 consumes less than 3 watts of power. You can mount this unit vertically or horizontally in any FA-M3 rack. Yokogawa Electric Corporation manufactures this precision measurement module. The Yokogawa AAT145-S00 belongs to the FA-M3 series controller family. This module carries CE and UL certifications for global deployment.
Details
| Weight | 0.7 kg |
|---|---|
| Dimensions | 2.5 × 20.3 × 15.2 mm |
