The Yokogawa AAP135-S00/K4A00 delivers precision pulse input processing for Centum VP and CS 3000 distributed control systems. It accurately measures rotational speed, flow rates, and accumulated totals from field instruments. This module provides reliable data acquisition for critical rotating equipment in demanding process applications.
Advanced Pulse Counting with Enhanced Termination
We engineer this module with 8 isolated pulse input channels for comprehensive monitoring of multiple rotating devices. The /K4A00 suffix indicates KL5 connector termination for secure and reliable field wiring connections. Each channel accepts signals from turbine flowmeters, encoders, and magnetic pickups with high accuracy. Consequently, process engineers obtain superior measurement performance with robust field termination.
Technical Specifications and Physical Characteristics
The AAP135-S00/K4A00 utilizes high-speed counting circuits for precise frequency measurement up to 10 kHz. It features channel-to-channel isolation to prevent interference between different input signals. The module provides both instantaneous frequency and 32-bit accumulated total values per channel. The KL5 connector interface ensures reliable connections in high-vibration industrial environments.
| Specification | Details |
|---|---|
| Product Model | AAP135-S00/K4A00 |
| Module Type | Pulse Input Module |
| Termination Type | KL5 connector interface |
| Compatible Systems | Centum VP, Centum CS 3000, Centum CS 1000 |
| Number of Channels | 8 isolated pulse inputs |
| Input Signal Types | Voltage pulse, contact closure, open collector, magnetic pickup |
| Input Voltage Range | 0–24 V DC |
| Maximum Count Rate | 10 kHz |
| Minimum Pulse Width | 50 µs |
| Counter Resolution | 32-bit accumulator per channel |
| Measurement Modes | Frequency, period, totalized count, rotational speed |
| Isolation | Channel-to-channel and channel-to-system isolation |
| Input Protection | Overvoltage and reverse polarity protection |
| Physical Dimensions | Standard Yokogawa I/O module format |
| Module Weight | Approximately 0.43 kg (0.95 lb) |
| Power Consumption | 5.0 W maximum |
Seamless Integration with Centum Control Systems
You can configure this module effortlessly using the Centum engineering workstation software environment. The Yokogawa AAP135-S00/K4A00 automatically integrates with the system’s I/O database for straightforward setup. It supports both local and remote I/O configurations for maximum installation flexibility. Therefore, process engineers achieve optimal monitoring of flow and speed measurements throughout the facility.
Furthermore, this module excels in applications requiring secure terminations and precise pulse monitoring. Industries like refining, petrochemicals, and power generation benefit from the KL5 connector design. The 32-bit accumulators provide long-term totalization without overflow concerns for extended campaigns. This capability ensures accurate material balance calculations and custody transfer measurements for billing purposes.
We source this precision module from Yokogawa Electric Corporation, a global leader in process automation solutions. As part of the Centum series I/O family, it guarantees compatibility with existing and new installations. Choosing the AAP135-S00/K4A00 means investing in reliable pulse input monitoring with secure connector terminations.
Technical Specifications Overview
| Specification | Details |
|---|---|
| Product Model | AAP135-S00/K4A00 |
| Module Type | Pulse Input Module |
| Termination Type | KL5 connector interface |
| Compatible Systems | Centum VP, Centum CS 3000, Centum CS 1000, Centum CS 3000 R3 |
| Number of Channels | 8 isolated pulse inputs |
| Input Signal Types | Voltage pulse, contact closure, open collector, magnetic pickup |
| Input Voltage Range | 0–24 V DC |
| Input Threshold | 2.5 V DC nominal (adjustable) |
| Maximum Count Rate | 10 kHz |
| Minimum Pulse Width | 50 µs |
| Counter Resolution | 32-bit accumulator per channel |
| Measurement Modes | Frequency, period, totalized count, rotational speed |
| Frequency Range | 0.01 Hz to 10 kHz |
| Accuracy | ±0.1% of reading |
| Isolation | Channel-to-channel and channel-to-system isolation |
| Withstand Voltage | 1500 V AC for one minute |
| Input Protection | Overvoltage and reverse polarity protection |
| Physical Dimensions | Standard Yokogawa I/O module format |
| Module Width | 30 mm |
| Module Height | 128 mm |
| Module Depth | 120 mm |
| Module Weight | Approximately 0.43 kg (0.95 lb) |
| Power Consumption | 5.0 W maximum |
| Current Draw | 220 mA from 5 V DC, 90 mA from 24 V DC |
| Connector Type | KL5 female connector |
| Status Indicators | LED for channel and module status |
| Operating Temperature | 0 to 50°C (32 to 122°F) |
| Storage Temperature | -20 to 70°C (-4 to 158°F) |
| Series | Centum I/O |
| Manufacturer | Yokogawa Electric Corporation |
Details
| Weight | 0.7 kg |
|---|---|
| Dimensions | 2.5 × 20.3 × 15.2 mm |
