This industrial control module provides reliable processing capabilities for factory automation systems. Xycom engineered this unit to deliver consistent performance in demanding manufacturing environments. Technicians will appreciate its straightforward integration and robust construction.
Core Technical Specifications
The Xycom 97011 features a compact form factor suitable for standard industrial enclosures. Its modular design allows flexible placement within control cabinets. The table below outlines the key technical parameters.
| Parameter | Specification |
|---|---|
| Module Type | Industrial Control Module |
| Power Input | 24 VDC nominal |
| Power Consumption | 15 W typical |
| Dimensions (W x H x D) | 6.2 x 4.5 x 1.8 inches |
| Weight | 1.2 lbs (0.54 kg) |
| Communication Interface | RS-232, RS-485 serial ports |
| Component Count | Single main PCB with 3 expansion headers |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -20°C to 70°C |
| Protection Rating | Conformal coated PCB |
Mechanical Architecture and Component Layout
Engineers will find the internal layout of this control module highly efficient. The Xycom 97011 contains a single main circuit board with three expansion headers. This configuration allows system integrators to add functionality as needed. Additionally, the conformal coating protects sensitive components from moisture and airborne contaminants. This protection significantly extends the module’s service life in harsh environments.
Power Management and System Integration
Furthermore, this module operates efficiently on a standard 24 VDC power supply. Its power regulation circuitry includes built-in transient suppression for industrial electrical environments. You can connect the unit directly to PLCs, PC-based controllers, or static trip relay systems. For protective relay applications, this module pairs seamlessly with components like the RMS TSG TZ C Static Trip series. The dual serial interfaces support simultaneous communication with multiple automation devices.
Environmental Durability and Installation
The compact dimensions enable installation in tight control cabinet spaces. Moreover, the operating temperature range spans 0°C to 55°C, ensuring stable performance across diverse conditions. Xycom (now part of Emerson Automation) designed this series for extended service life in demanding industrial applications. The modular form factor simplifies replacement procedures during scheduled maintenance.
