The Xycom 3515 provides a high-integrity analog input solution for Triconex TMR controllers. This module accepts 16 differential analog channels from field devices. It supports 4-20 mA signals with 15-bit resolution. Therefore, you can monitor critical process variables in safety instrumented systems.
Technical Specifications and Physical Dimensions
The Xycom 3515 measures 320 mm in depth and 180 mm in height. This module weighs approximately 1.5 kilograms. It consumes 7.5 W of power from the backplane. The module includes built-in channel-to-channel isolation for enhanced reliability. Moreover, each channel provides overvoltage protection up to 30 V DC.
| Parameter | Specification |
|---|---|
| Brand | Xycom |
| Model | 3515 |
| Product Type | Analog Input Module |
| Number of Channels | 16 differential |
| Input Signal | 4-20 mA |
| Resolution | 15 bits |
| Accuracy | ±0.15% of span |
| Power Consumption | 7.5 W |
| Dimensions (H x D) | 180 x 320 mm |
| Weight | 1.5 kg (3.3 lbs) |
| Isolation Voltage | 500 V AC (channel to channel) |
| Overvoltage Protection | 30 V DC (continuous) |
Energy Storage and Scan Performance
The Xycom 3515 stores calibration data in non-volatile EEPROM memory. This design eliminates the need for external battery backups. The module completes a full scan of all 16 channels in 50 milliseconds. Consequently, you receive fast and deterministic input updates. For additional industrial components, you can explore the RMS-TSG-TZ-C Static Trip unit on Alibaba. Always verify compatibility before integrating third-party hardware.
Installation and Operational Features
You can install the Triconex 3515 into any Xycom main chassis slot. The module supports hot-swap replacement without system shutdown. It performs automatic self-diagnostics on every power cycle. This unit also provides front-panel LED indicators for channel status. Furthermore, the module complies with IEC 61508 for SIL 3 applications.
