The Xycom 9450 9450-0486614010000 serves as a versatile VMEbus automation controller for industrial systems. This module combines processing power with flexible I/O expansion capabilities. Consequently, engineers can deploy it for data acquisition or machine control tasks. The Xycom 9450 9450-0486614010000 operates as a standalone intelligent node on the VMEbus backplane.
This automation board features a PC/104 expansion connector for adding standard modules. Therefore, you can customize the unit with extra serial ports or networking interfaces. The Xycom 9450 9450-0486614010000 supports both master and slave bus configurations.
Technical Specifications
Many system integrators pair this controller with protection relays like the RMS-TSG-TZ-C Static Trip for complete automation safety . The Xycom delivers dependable performance for critical industrial processes.
| Parameter | Specification |
|---|---|
| Manufacturer | Xycom (now Emerson) |
| Model | 9450 (9450-0486614010000) |
| Type | VMEbus Automation Module / Controller Board |
| Form Factor | 6U VMEbus |
| Current Consumption | 0.9 A (5V DC typical) |
| Weight | Approx. 0.45 kg (1.0 lb) |
| Dimensions (HxWxD) | 233 x 20 x 160 mm |
| Expansion Slot | PC/104 (16-bit) |
| Bus Interface | VMEbus P1/P2 connector |
| Energy Storage | Minimal (filter capacitors only) |
Hardware & Interface Details
The Xycom 9450 9450-0486614010000 includes a PC/104 connector for stacking expansion modules. You can attach up to four additional boards for extended functionality. This module provides onboard memory for program and data storage. The design uses surface-mount components for improved shock and vibration resistance.
Furthermore, this automation module features a watchdog timer for fail-safe operation. It automatically resets the board if software execution stops unexpectedly. The Xycom 9450 9450-0486614010000 also offers configurable base address jumpers for easy system integration.
Installation & Power Management
This VMEbus module draws only 0.9 A from the 5V DC backplane supply. It stores negligible energy in capacitors, allowing safe hot-swapping in most systems. Engineers appreciate the passive backplane design for simplifying maintenance and repairs. You can replace this board without powering down the entire chassis.
The operating temperature ranges from 0°C to 55°C for standard industrial environments. For extended temperature needs, Xycom offers alternative ruggedized versions. This module works seamlessly with the 9712KP flat-panel HMIs for complete operator workstations.
