The Xycom 143635 provides a dedicated operator interface for industrial automation systems. This terminal features a monochrome LCD display with backlight for clear visibility. Consequently, operators can monitor machine status and enter commands with ease. The unit includes a membrane keypad with programmable function keys for customized control.
This operator interface communicates with PLCs and other controllers via serial protocols. Therefore, it suits legacy systems requiring reliable text-based operator terminals. The Xycom 143635 mounts easily into standard panel cutouts for quick installation.
Technical Specifications
Many facilities pair this HMI with protection relays like the RMS-TSG-TZ-C Static Trip for complete system monitoring . The Xycom 143635 delivers dependable operator interaction for critical production processes.
| Parameter | Specification |
|---|---|
| Manufacturer | Xycom (now Emerson) |
| Model | 143635 |
| Type | Operator Interface / Industrial HMI Terminal |
| Display Type | Monochrome LCD with backlight |
| Display Size | 5.7 inches diagonal |
| Resolution | 320 x 240 pixels (QVGA) |
| Keypad | Membrane with 24 programmable keys |
| Dimensions (HxWxD) | 180 x 240 x 55 mm |
| Weight | Approx. 2.3 kg (5.1 lbs) |
| Current Consumption | 0.5 A (24 VDC typical) |
| Front Panel Rating | NEMA 4 / IP65 |
| Communication Ports | RS-232C, RS-422 (selectable) |
Hardware & Interface Details
The Xycom 143635 includes one RS-232C port and one RS-422 port for flexible connectivity. You can connect this terminal to most major PLC brands without special converters. The unit features a 24-key membrane keypad with tactile feedback for reliable data entry. Each key has an LED indicator for operator guidance during use.
Furthermore, this operator interface stores configuration data in non-volatile memory. It retains all settings without battery backup, eliminating routine maintenance. The Xycom 143635 also provides a rear-mounted DIP switch block for protocol selection.
Installation & Power Management
This operator interface draws only 0.5 A from a 24 VDC power source. It contains no internal batteries, so you never need to replace energy storage cells. You can mount this unit using the included panel-mounting clips and sealing gasket. The NEMA 4 front panel withstands water jets and dust ingress effectively.
Engineers choose the Xycom 143635 for its simple yet rugged design. The operating temperature ranges from 0°C to 50°C for standard factory environments. For outdoor use, you will need additional sun protection for the LCD display.
Details
| Weight | 2.85 kg |
|---|---|
| Dimensions | 41.2 × 17.8 × 6.2 mm |
