Core High-Performance Network Connectivity

The Woodward SST-PFB3-PCI is a multi-protocol PROFIBUS interface card for industrial PCs. This card provides high-speed, deterministic connectivity between PCI bus computers and PROFIBUS DP networks. It supports a comprehensive range of protocols including DP-Master V Classes 1 & 2 and DP-Slave V0. Consequently, it serves diverse automation needs from simple data acquisition to complex master/slave control tasks.

Advanced Protocol Support and Key Features

This interface card can execute Master, Slave, and FDL (Layer 2) send/receive functions simultaneously. It manages DP-V1 services and includes an OPC Data Access server for seamless integration. The SST-PFB3-PCI achieves high-speed data transfer rates up to 12 Mbps for responsive system performance. Furthermore, its dual-port RAM interface ensures portability across various PC operating systems.

Technical Specifications and System Integration

Equipped with internal flash memory, the card stores configuration data independently from the host PC. It facilitates fast commissioning through dedicated DP configuration and diagnostic software tools. The following table details its primary protocol support, performance, and compatibility parameters.

Application and Commissioning Benefits

Use this card to integrate a standard industrial PC directly into a PROFIBUS DP control network. Its advanced capabilities allow access to DP-V1 and PA variables from PC-based applications. The Woodward SST-PFB3-PCI simplifies system integration and supports reliable 24/7 operation. Therefore, it is an ideal solution for PC-based control, SCADA systems, and network gateways requiring robust PROFIBUS communication.
