The Woodward 9907-076 is a robust industrial power supply module, designated Revision F. This unit efficiently converts a wide-range AC input into a stable 24V DC output. Moreover, it delivers reliable power for critical control systems and electronic loads.

Input and Output Electrical Specifications

This module accepts a broad AC input voltage range from 88 to 132 volts. It provides a substantial output capacity of 24 volts DC at up to 16 amps. Consequently, the supply can support demanding applications with consistent, regulated power.

Detailed Technical Parameters

The 9907-076 Rev F combines high power density with industrial durability. Below are its comprehensive technical specifications for system design.

Technical Specifications:

• Manufacturer & Model: Woodward 9907-076 (Revision F)

• Product Category: AC/DC Power Supply Module

• Input Voltage Range: 88 – 132 V AC

• Input Frequency: Typically 50/60 Hz (consult datasheet for exact range)

• Output Voltage: 24 V DC (regulated)

• Output Current: 16 A maximum continuous

• Output Power: Approximately 384 Watts (24V * 16A)

• Efficiency: High-efficiency design to minimize heat generation

• Protection Features: Includes over-current, over-voltage, and short-circuit protection

• Cooling Method: Convection or fan-cooled, depending on specific configuration

• Form Factor: Industrial enclosed design for panel or DIN-rail mounting

• Dimensions: Compact footprint for efficient use of panel space (exact dimensions vary).

• Weight: Robust construction for heat dissipation and mechanical stability.

• Electrical Interface: Terminal block connections for AC input and DC output wiring.

• Internal Components: Contains transformer, rectifier bridge, filtering capacitors, and regulation circuitry.

• Status Indication: May include LED indicators for power and fault conditions.

• Operating Temperature: Designed for reliable performance in standard industrial ambient ranges.

• Certifications: Likely carries standard industrial safety and EMC certifications.

Application and System Integration

The Woodward 9907-076 is essential for powering control racks, I/O modules, and actuators in various settings. It provides the backbone power for automation systems in power generation and heavy industry. For example, it can supply power to a control chassis housing components like the IS200AEBMG1AFB. This supply may also support auxiliary systems that include protective relays like the RMS-TSG-TZ-C Static Trip unit or monitoring devices such as the PR6423/128-110.
