The Woodward 5501-471 NetCon 5000B SIO module provides dual serial communication ports. This module integrates seamlessly with all MicroNet Plus control systems for external device connectivity. Moreover, it serves as a direct, enhanced replacement for the earlier 5501-470 module. Consequently, you gain a reliable interface for data loggers, vibration monitors, and remote PLCs.

Enhanced Communication Capabilities

This SIO module features two independent RS-232 serial ports for flexible connections. Furthermore, it adds crucial support for RS-422 and RS-485 multi-drop communication standards. The module also allows for programmable baud rates and parity settings up to 115.2 kbps. Therefore, it ensures optimal compatibility with a vast array of industrial peripherals.

Improved Buffer and Performance Specifications

The 5501-471 includes a 128-byte receive buffer for robust data handling. It also features a dedicated 32-byte transmit buffer for smooth outgoing communication. These enhancements effectively prevent data loss during high-speed serial exchanges. Additionally, the module maintains full electrical and mechanical compatibility with its predecessor.

Detailed Technical Parameters

Complete Specifications for Woodward 5501-471:

• Manufacturer & Model: Woodward 5501-471

• Product Series: NetCon 5000B Serial I/O (SIO) Module

• Compatibility: Fully compatible with all MicroNet Plus control systems.

• Primary Function: Provides serial communication interface for external devices.

• Communication Ports: 2 independent serial ports.

• Supported Standards: RS-232, RS-422, and RS-485.

• Maximum Baud Rate: Programmable up to 115,200 bps.

• Data Buffers: 128-byte receive buffer, 32-byte transmit buffer.

• Configuration: Software-programmable baud rate, parity, and data format.

• Replacement Role: Direct drop-in upgrade for the older 5501-470 module.

• Typical Connected Devices: Vibration monitoring systems, data loggers, HMIs, and remote PLCs.

• Mounting: Installs directly into the designated slot on the MicroNet Plus board.

• Power Supply: Powered from the MicroNet Plus system backplane.

• Availability: Available as both new and certified refurbished units.

Reliable System Integration and Upgrade Path

Integrating this module extends the communication capabilities of your MicroNet Plus system. Its enhanced buffers and protocol support future-proof your control architecture. Ultimately, the Woodward 5501-471 is a versatile and reliable solution for industrial serial networking.
