Enabling Critical Data Exchange Within Control Systems
The Woodward 5466-353 is a vital transceiver module designed for main chassis installation. This component facilitates essential data communication between the controller and other system parts. It mounts directly into a dedicated slot within a Woodward main chassis. Consequently, it ensures reliable and high-integrity signal transmission for critical control applications.
Technical Specifications and Physical Integration
This transceiver module from Woodward is engineered for robust industrial performance. Its slot-mountable design provides a secure electrical and mechanical connection. Furthermore, the module operates within the specific power and signal parameters of the host chassis.
Detailed Technical Parameters
| Parameter | Specification |
|---|---|
| Manufacturer | Woodward |
| Model Number | 5466-353 |
| Typical Host System | Woodward Governor Control Systems (e.g., PRO-TECH 203, 505/505E) |
| Product Category | Transceiver Module / Communication Interface Card |
| Mounting Location | Main Control Chassis (Slot-mounted) |
| Primary Function | Bidirectional Data Transmission & Reception |
| Communication Protocol | Proprietary Woodward Digital Network (e.g., for ACT panels) |
| Data Transfer Rate | System-dependent, optimized for real-time control |
| Number of Ports/Channels | 1 (Typical for main chassis backplane interface) |
| Interface Type | Electrical connection via chassis backplane connector |
| Operating Voltage | 5 VDC or 12 VDC (Supplied from chassis backplane) |
| Typical Power Consumption | < 2 Watts |
| Operating Temperature Range | 0°C to 70°C (32°F to 158°F) – Typical for control room hardware |
| Storage Temperature Range | -40°C to 85°C (-40°F to 185°F) |
| Module Dimensions | Standard Eurocard or proprietary slot card size |
| Module Weight | Approximately 0.15 kg |
| Connector Type | Edge-card connector for direct backplane insertion |
| Status Indicators | LEDs for Power, Transmit (Tx), Receive (Rx), Fault |
| Isolation | Optical or galvanic isolation for noise immunity (typical) |
| Internal Energy Storage | None; requires continuous chassis power |
| Component Count | 1 Module Unit |
| Compliance | Designed for industrial EMC/EMI environments |
Key Features and System Role
The 5466-353 module acts as the communication gateway for the main control processor. It transmits control commands to remote I/O or actuator modules and receives feedback data. The module also provides electrical isolation to protect the central processor from field-side disturbances. Moreover, its LED indicators offer immediate visual status for simplified diagnostics. Therefore, it is a critical component in turbine and engine control systems for power generation and marine propulsion.
Application Context and Network Integration
This transceiver is integral to Woodward’s distributed control architectures. Typically, it connects the main 5466-XXX series chassis to remote panels or other chassis over a dedicated network. For example, it enables communication between a PRO-TECH 203 governor and its actuator driver modules. The module ensures deterministic data exchange necessary for precise speed and load control.
Installation and Replacement Procedure
First, ensure the main chassis is powered down completely before module handling. Next, carefully align the 5466-353 module with the guide rails of its designated slot. Then, insert the module firmly until the edge connector seats fully into the backplane. Finally, secure the module using the provided fastener or latch, and restore power to the chassis.
Details
| Weight | 0.91 kg |
|---|---|
| Dimensions | 273.6 × 214.1 × 59.2 mm |
