Core Dual-Channel Actuator Control
The Woodward 5464-210 is a robust dual-channel actuator driver module for industrial environments. This versatile unit controls two independent actuators simultaneously for enhanced system design flexibility. It delivers a high output current of up to 5 amps per channel to drive various actuator types. Consequently, it is a preferred solution for precise valve, damper, and pump control in demanding process applications.
Isolated Inputs and Configurable Signal Ranges
This module provides isolated inputs to protect against ground faults and ensure operational safety. It supports multiple configurable input and output signal ranges for broad compatibility. The 5464-210 accepts inputs of 0-10 VDC, 4-20 mA, or ±10 VDC depending on configuration. Furthermore, it features built-in on-board diagnostics for proactive maintenance and monitoring of module health.
Detailed Technical Specifications
Engineered for harsh conditions, the module operates reliably across an extreme temperature range. Its compact and rugged design ensures durability while simplifying installation in control panels. The following table details its comprehensive electrical, environmental, and physical parameters.
| Parameter | Specification |
|---|---|
| Manufacturer | Woodward |
| Product Model | 5464-210 |
| Module Type | Dual-Channel Actuator Driver |
| Channels | 2 Independent Channels |
| Output Current per Channel | Up to 5 A |
| Input Voltage | 24 V DC |
| Configurable Input Ranges | 0-10 VDC, 4-20 mA, ±10 VDC |
| Configurable Output Ranges | 0-12 V, 4-20 mA, 0-5 VDC |
| Key Feature | Isolated Inputs |
| Diagnostics | On-Board |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions (L x W x H) | 4.25″ x 2.75″ x 4.25″ (approx. 108mm x 70mm x 108mm) |
| Weight | 0.75 lbs (approx. 0.34 kg) |
Application in Process and Motion Control
Use this module for precise positioning control of valves in chemical, oil & gas, or water treatment processes. It is equally effective for managing damper position in industrial HVAC and ventilation systems. The Woodward 5464-210 also excels in pump control and motor speed/position regulation tasks. Therefore, it is a versatile and reliable component for diverse industrial automation and motion control challenges.
