The Woodward 5462-948 T/C card delivers precise temperature monitoring for critical processes. This dedicated thermocouple module interfaces directly with various sensor types. Furthermore, its multi-channel design supports comprehensive temperature profiling across equipment. System engineers rely on its accuracy for stable and efficient industrial operations.
Core Technical Specifications
The Woodward 5462-948 card integrates high-reliability signal conditioning components. It features a compact form factor for efficient use of panel space. Moreover, its design ensures stable readings even in electrically noisy environments.
Below are the detailed technical specifications for this interface module:
| Parameter Category | Specification Details |
|---|---|
| Manufacturer & Model | Woodward, 5462-948 |
| Product Designation | T/C Card (Thermocouple Interface Card) |
| Primary Function | Multi-channel Thermocouple Signal Conditioning |
| Input Channel Count | 8 Independent Thermocouple Channels |
| Key Internal Components | Multiple precision amplifier circuits, reference junctions, and filtering networks. |
| Typical Energy Storage | On-board capacitors for signal noise suppression and stabilization. |
| Country of Origin | United States (USA) |
| Design Characteristic | Compact, High-Density Layout |
Key Features and Application Role
This card conditions low-voltage signals from J, K, or T-type thermocouples. It converts these signals into robust, high-level analog outputs for the controller. Consequently, the Woodward 5462-948 enables accurate temperature control and alarming.
Its eight-channel capacity allows centralized monitoring of multiple points. Therefore, this module is ideal for turbines, compressors, and other critical machinery.
Details
| Weight | 0.91 kg |
|---|---|
| Dimensions | 273.6 × 214.1 × 59.2 mm |
